INSTALLATION AND OPERATING INSTRUCTIONS
WARNING: California Residents Only. This product can expose you to chemicals including
chromium which is known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information go to www.P65Warnings.ca.gov.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
WARNING: Improper installation, operation, service or maintenance can cause
property damage, injury or death. Read and understand these instructions
thoroughly before positioning, installing, maintaining or servicing this equipment.
Initial heating of appliance may generate smoke or fumes and must be done in a well ventilated area.
Overexposure to smoke or fumes may cause nausea or dizziness.
APW Wyott
cooking equipment has been engineered to provide you with year-round dependable service
®
when used according to the instructions in this manual and standard commercial kitchen practices.
Telephone: (800) 527-2100
DESIGNED SMART. BUILT SOLID.
Radiant Conveyor Toaster
Model: X*TREME
INTENDED FOR OTHER THAN HOUSEHOLD USE
APW Wyott Food Service Equipment Company
265 Hobson St. • Smithville, TN 37166
®
-1
®
1
2M-93100174 REV A 09/18
www.apwwyott.com
Advertisement
Table of Contents
Related Manuals for APW Wyott X TREME-1
Summary of Contents for APW Wyott X TREME-1
- Page 1 ® when used according to the instructions in this manual and standard commercial kitchen practices. 2M-93100174 REV A 09/18 APW Wyott Food Service Equipment Company 265 Hobson St. • Smithville, TN 37166 Telephone: (800) 527-2100 www.apwwyott.com...
-
Page 2: Table Of Contents
IMPORTANT: Read the following important safety instructions to avoid personal injury or death, and to avoid damage to the equipment or property. WARNING: APW Wyott toasters are designed, built, and sold for commercial use. If positioned where the general public can use them, make sure that all cautions, warnings, and operating instructions are clearly posted near each unit to insure proper operation, reduce the chance of personal injury and/or equipment damage. - Page 3 Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in APW Wyott equipment. It is essential to use APW Wyott Replacement Parts when repairing APW Wyott equipment. Failure to use APW Wyott Replacement Parts may subject operators of the equipment to hazardous electrical voltage, resulting in electrical shock or burn.
-
Page 4: General Information
CAUTION: Use only non-abrasive cleaners. Abrasive cleaners could scratch the finish of your unit, marring its appearance and making it susceptible to dirt accumulation. WARNING: Failure to provide clearances will cause unit failure and invalidate warranty claims (see installation instructions). NOTICE: Do not use toppings (butter, etc.) on product as product is inverted during normal operation. -
Page 5: Operation Instructions
4 . OPERATION INSTRUCTIONS 1. Preparation A. Clean toaster thoroughly before first use (See cleaning instructions). B. Controls Familiarity 1. Main Power Switch (located on very bottom of control panel): There are two rocker switches. The bottom switch powers the unit “ON”. It also turns on the bottom element. The top switch is a standby switch (upper heat switch) that runs the top element. -
Page 6: Specifications
D. Is the unit operating on proper voltage? 2. If problems exist after checking the above, check the chart below. 3. If any service is needed (italicized items), call an APW Wyott authorized service agency. All service should be performed by an APW Wyott authorized service agency. -
Page 7: Parts List With Exploded View
8 . PARTS LIST WITH EXPLODED VIEW EXPLODED VIEW Item Description 93100158 RIVET ASSY, XTRM-1 INNER CORE 93100160 XTRM-1 CONTROL PANEL EXTRUSION 93100162 XTRM-1 RIGHT SIDE EXTRUSION 93100150 XTRM-1 TOP COVER LEFT 93100061 XTRM-1 PANEL, LEFT OUTER 93100060 XTRM-1 PANEL, RIGHT OUTER 93000067 END CAP, F/L &... - Page 8 Item Description 93100047 XTRM-1 ELEMENT END CAP 89061 NUT, HEX 10-24 83248 BEARING, SHAFT 83821 BRACKET, BEARING 38130 ASSY, CLIP BEARING 38125 BEARING FLANGED POLYMER 38122 W’ASSY IDLER SHAFT 89184 BUSHING, .875 HEYCO 2126 85286 FAN MOTOR COOLING 120V 85248 FAN MOTOR COOLING 208, 230/240V 85152 MOTOR AT10 115V 60HZ...
-
Page 9: Wiring Diagram
IMPORTANT NOTICE: The information contained in this section of the manual is intended for individuals possessing backgrounds of electrical and mechanical experience, such as an authorized APW Wyott service technician. APW or the seller cannot be responsible for the interpretation of this information, nor can it assume... - Page 10 Date Purchased Notes APW Wyott takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment. To ensure best results, it is important that you read and follow the instructions in this manual carefully.
-
Page 11: Warranty
LIMITED EQUIPMENT WARRANTY WARRANTY EXCLUSIONS APW warrants to the original purchaser of new APW's products to be THE FOLLOWING WILL NOT BE COVERED UNDER WARRANTY. free from defects in material or workmanship, under normal and proper APWs’ sole obligation under this warranty is limited to either repair use and maintenance service as specified by APW and upon proper or replacement parts, subject to the additional limitations installation and start-up in accordance with the instructions...
