Step 1: Prepare the
mounting surface by
attaching a board
(typically plywood, 3/4"
to 1" thick) to the wall.
(The board must be
attached to a stud in
the wall for stability.)
Mounting Guide, 61210916L1-19A, May 2005
TOTAL ACCESS 900 SERIES MOUNTING CONFIGURATIONS
Step 2: Wallmount the
Total Access 900 Series
unit using two 3/32" to
1/8" (1 1/2" or greater in
length) wood screws.
Technical Support 1-888-4ADTRAN (1-888-423-8726)
For more detailed documentation, visit us online at
LEDs Pointing Down
www.adtran.com
P/N 1210916L1
LEDs Pointing Sideways
Copyright © 2005 ADTRAN, All Rights Reserved
