MAIN SCREEN
OPERATION
To perform this action:
Change the screen format
Display system status
Display cameras sequentially
Log in
Log out
Shut down the unit*
Generate an alarm*
Clear latched alarm messages* Click Utility. Click Clear Latched. Click Yes.
Back up the image database*
Restore archived images*
Play archived images*
Add, change or delete a user*
Configure the record schedule* Click Setup. Click Schedule.
Configure other unit settings*
Review an alarm*
Search the image database*
Use the filters to search the
image database*
Play back images*
Configure IntelleCord filters*
NOTE: You must have permission from the system adminis-
trator to access items marked with an '*'.
Do this:
Click or press a screen format button (1x1, 2x2, 3x3, 4x4).
Click or press Status.
Click or press Seq.
Enter your PIN. Click OK.
Click Utility. Click Log Out. Click Yes.
Click Utility. Click Shutdown. Click Yes.
Click Utility. Click Generate Alarms. Select the cameras. Click
OK to generate alarms for the selected cameras.
Click Archive. Click Back up... Follow the directions.
Click Archive. Click Restore... Follow the directions.
Click Archive. Click Play... Follow the directions.
Click Setup. Click Security.
Refer to Chapter 3 — System Configuration in the Intellex
Installation Instructions.
Click or press Alarms. Select an alarm segment to review. Click
or press Play.
Click Search. Select the search conditions. Click Find.
Refer to Chapter 3 — Playback Operation in the Intellex
Operating Instructions.
Click or press a camera button. Click or press Play/Pause.
Refer to Chapter 3 — System Configuration in the Intellex
Installation Instructions.
Quick Reference Guide
