KTM 50 SX 2012 Setup Instructions

2012
Hide thumbs Also See for 50 SX 2012:

Advertisement

Quick Links

Download this manual
SETUP INSTRUCTIONS
2012
50 SX
50 SX Mini
Art. no. 3211878en

Advertisement

loading
Need help?

Need help?

Do you have a question about the 50 SX 2012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KTM 50 SX 2012

Summary of Contents for KTM 50 SX 2012

  • Page 1 SETUP INSTRUCTIONS 2012 50 SX 50 SX Mini Art. no. 3211878en...
  • Page 3 KTM accepts no liability for delivery options, deviations from illustrations and descriptions, as well as misprints and other errors.

  • Page 4: Means Of Representation

    MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 Fill up with oil. ( p. 6) 700540-01 – Remove the motorcycle from the lift stand. ( p. 4) – Rest the vehicle on the plug-in stand. – Print out the current PDI form found on KTM DEALER.NET and perform the delivery inspection.
  • Page 6 WORK Raising the motorcycle with a lift stand Note Danger of damage The parked vehicle may roll away or fall over. – Always place the vehicle on a firm and even surface. – Raise the motorcycle at the frame underneath the engine. Lift stand (59229055000) The tires should no longer be in contact with the ground.
  • Page 7 WORK – Position the handlebar clamps. Mount and evenly tighten the four screws Guideline Screw, handlebar clamp 20 Nm (14.8 lbf ft) Info Make sure the gap width is even. Installing the chain guard (50 SX) – Position the chain guard. Mount cable binder Info The cable binder must be run between chain sliding guard swingarm...
  • Page 8 WORK Filling up with oil (50 SX Mini) Warning Engine failure If the vehicle is run without 2-stroke oil in the tank, the result is engine failure. – The oil tank must always be filled up to the MIN mark. – Switch off the engine.

  • Page 9: Technical Data - Chassis Tightening Torques

    TECHNICAL DATA - CHASSIS TIGHTENING TORQUES – Spoke nipple M3.5 3 Nm (2.2 lbf ft) – Screw, brake linings 8 Nm (5.9 lbf ft) ® Rear brake caliper screw 10 Nm (7.4 lbf ft) Loctite 243™ – Remaining nuts, chassis 10 Nm (7.4 lbf ft) –...
  • Page 10 2-stroke engine oil According to – JASO FC ( p. 9) Guideline – ® Only use high quality 2-stroke engine oil of a well-known brand. KTM recommends Motorex products. Fully synthetic Supplier ® Motorex – Cross Power 2T Super unleaded (ROZ 95/RON 95/PON 91) According to –...
  • Page 11 STANDARDS JASO FC JASO FC is a classification for a 2-stroke engine oil that was specifically developed for the extreme demands of racing. Thanks to first rate synthetic esters and specially designed additives, superb combustion is achieved even under extreme operating conditions.
  • Page 12 *3211878en* 3211878en KTM-Sportmotorcycle AG 5230 Mattighofen/Austria http://www.ktm.com...

This manual is also suitable for:

50 sx mini 2012
