Hunter ICC 2 Quick Start Programming Manual page 2

HIDDEN AND ADVANCED FEATURES
Feature Where Found
PROGRAMMABLE SENSOR OVERRIDE
Hold
CYCLE AND SOAK
Hold
DELAY BETWEEN STATIONS
Hold
HIDE PROGRAMS
Hold
SOLAR SYNC DELAY
Hold
CLIK DELAY
Hold
TOTAL RUN TIME Turn to Run Times.
Press ◄ when station 1 is shown,
PRG to select other programs.
Hold PRG 3 secs.
TEST PROGRAM
EASY RETRIEVE
TM Hold
Hold
TOTAL RESET PRG and RESET button
QUICK CHECK + –
TM ,
RUN PROGRAM Hold ►, PRG to select
TROUBLESHOOTING GUIDE
Display Possible Cause
DISPLAY SHOWS "ERR" WITH NUMBER Short in field wiring, or bad solenoid.
DISPLAY SHOWS P "ERR" Short in Pump/Master Valve wiring or solenoid.
DISPLAY SHOWS SP "ERR" SmartPort error. Electrical noise is present near connection to remote or other SmartPort device.
DISPLAY SHOWS "NO AC" There is no AC power to the controller.
DISPLAY SHOWS WATERING BUT NO Problem in field wiring.Problem with solenoids. No water pressure to system.
WATER IS OCCURRING
FROZEN OR GARBLED DISPLAY Power surge
RAIN SENSOR DOES NOT STOP Jumper wire is not removed. Sensor switch in
IRRIGATION BYPASS position.
CONTROLLER SEEMS TO WATER Too many start times.
CONTINUOUSLY
© 2016 Hunter Industries Incorporated | hunterindustries.com
–
and turn to Start Times
+
and turn to Run Times. Enter Cycle, press PRG to set Soak
–
and turn to Run Times
–
and turn to Water Days
+
and turn to Solar Sync
+
and turn to Off
+
and PRG to Save
–
and PRG to Restore
+
, ◄, ► together, then
LIT-666 - QG -US 6/16
Description
Sets individual stations to ignore sensor shutdowns. Select stations with ◄ or ►, (use
to OFF to ignore sensor.
Sets max time a station can run at once, and minimum time it must wait before another cycle.
Divides run time into segments to prevent runoff.
Inserts a delay (seconds or minutes) between stations in a run time, for slow valves or recharging tanks.
–
+
Use / to change from 4 to 1 to hide extra programs. 1 will show only program A,
start time 1. 4 will show all programs and start times.
Set number of days before Solar Sync begins adjusting run times. Allows landscape establishment for a
set period of days, before Solar Sync begins adjusting automatically.
Set number of days for watering to remain off, after sensor has been activated and restored.
Calculates and displays total of all run times in a program start time.
Runs all stations in controller for the time entered for test or diagnostic purposes.
Saves all program information to restore at a later time.
Erases all watering information.
Checks all stations for wiring problems.
Runs all stations in selected program; use ► to advance to next station manually.
Solutions
Check field wiring and valve solenoid. Press any button to clear ERR message.
Check wiring and solenoid at PMV. Check specifications for Pump Start Relay.
Move connections away from sources of electrical noise.
Check fuse/breaker and incoming power supply to controller.
Check field wiring (voltmeter). Check valve solenoid(s). Verify water source is open.
Reset controller.
Remove jumper wire on SEN terminals. Set sensor switch to Active position.
One Start Time operates all stations in a program. Remove unnecessary start times.
–
+
/ ) to change
http:/ / hunter.direct/icc2help
