- Page 1 CPC507 3U CPCI Serial Elbrus CPU Module User Manual Rev. 001 February 2021 The product described in this manual is compliant with all related CE standards.
- Page 2 Product Title: CPC507 Document name: CPC507 User Manual Manual version: 001 Ref. docs: Copyright © 2021 Fastwel Co. Ltd. All rights reserved. Revision Record Rev. Index Brief Description Product Index Date Initial version CPC507 February 2021 Contact Information Fastwel Co. Ltd...
-
Page 3: Table Of Contents
6.2 Advanced …………………………………………………………………………………………………………………..52 7. TROUBLESHOOTING………………………………………………..………………………………………………………53 8. POWER CONSUMPTION……………………………………………………..……………………………………………..54 9. INFLUENCE OF EXTERNAL FACTORS…………………………………….……………………………..…………...55 9.1 CPC507 operating conditions and MTBF…………………………………………………………………………..…..55 ANNEX A: TERMS, ACRONYMS AND ABBREVIATIONS …………………….……………………………………………..56 ANNEX B: DICSLAIMER…………………………………………………………………………………………………..……….58 © 2 0 2 1 C P C 5 0 7... -
Page 4: List Of Tables
List of Tables Table 2 1: System information……..……………………………………………………………………………………………..15 Table 3-1: Purpose of XMC1 XS7 (P15) and XMC2 XS8 (P15) connectors pins on the CPC507 board ……………..22 Table 3-2: PMC connector pin assignment…………………………………………………………………………………….24 Table 1-1: Assignment of SATA XS6 connector pins………………………………………………………………………...25 Table 3-4: Assignment of XP2 connector pins………………………………………………………………………………...26... -
Page 5: List Of Figures
This document contains information, which is property of Fastwel Co. Ltd. It is not allowed to reproduce it or transmit by any means, to translate the document or to convert it to any electronic form in full or in parts without antecedent written approval of Fastwel Co. Ltd. or one of its officially authorized agents. - Page 6 CPC507 Ownership rights This document contains information that is the property of Fastwel Group. It may not be copied or transmitted by any known means, nor may it be stored in information storage and retrieval systems without the prior written consent of Fastwel Group or one of its authorized agents. The information...
-
Page 7: Conventions
CPC507 Conventions Caution, High Voltage! This sign and text warn of the dangers associated with electrical discharges (> 60 V) when touching the device or any part of it. Failure to follow the precautions mentioned or prescribed in the regulations may endanger your life or health, and may result in damages to the equipment. - Page 8 CPC507 Safety requirements This Fastwel Group product has been developed and tested to ensure compliance with electrical safety requirements. Its design provides long-term fail-safe operation. The product's life cycle may be significantly shortened due to mishandling during unpacking and installation. Therefore, for your own safety and for ensuring proper operation of the device, you should follow the recommendations given below.
-
Page 9: General Rules Of Usage
Fastwel Group other than those contained in this User Manual or received from the technical support service of Fastwel Group in the form of a set of instructions for their implementation will void the warranty. - Page 10 CPC507 For customized products, the warranty period is 60 months from the date of sale (unless otherwise provided by the delivery agreement). Limitation of warranty obligations The above warranty does not apply to: - the products (including software) that have been repaired or modified by the employees who do not represent the Manufacturer.
-
Page 11: Transportation, Unpacking And Storage
CPC507 Transportation, Unpacking and Storage Transportation The modules should be transported in the separate manufacturer’s packaging (container), consisting of an individual antistatic packaging and a cardboard box, in closed transport (road, rail, air in heated and sealed compartments) under storage conditions 5 according to the GOST standard 15150-69 or under storage conditions 3 for sea transportation. - Page 12 If a product should fail through Fastwel's fault during the warranty period, it will be repaired free of charge. For out of warranty repairs, the customer will be invoiced for repair charges at current standard labor and materials rates.
-
Page 13: Introductioin
Introduction System overview The CPC507 CompactPCI (CPCI) CPU module (presented in this User Manual) supports the PCI architecture. This allows you to work with a wide range of equipment. To get the information on the CompactPCI standard, please refer to the PCI and CompactPCI Standards Specification. For more information on these standards and their use, please visit the official website of the PCI Industrial Computer Manufacturers Group (PICMG) at: http://www.picmg.org/. -
Page 14: General Information
CPC507 General Information General Features of CPC507 ● Processor AMD Ryzen Embedded V1404I SoC APU 2.0GHz 25 W: - 4 x cores x64, 8 x threads; - 8 x graphics cores; - 6MB cache; ● RAM: - DDR4-2400 SDRAM up to 16 GB with ECC support;... - Page 15 CPC507 - Capacity 32 GB; - SATA III 6 Gbps interface; ● SATA Interface: - One interface is routed to the CFast connector; - One interface is used for connecting integrated SSD. ● SPI Interface: - FRAM support; - Frequency up to 25 MHz.
-
Page 16: Compatibility With The Picmg/Vita Standards
Module versions CPC507-01 – CPC507 CPU-module, AMD Ryzen Embedded V1404I 2.0GHZ 4 Cores, 16GB DDR4 SDRAM, -40…+70 C CPC507-02 – CPC507 CPU-module, AMD Ryzen Embedded V1404I 1.7GHZ 4 Cores, 8GB DDR4 SDRAM, -40…+85 C Available options: \COATED – Conformal coating. -
Page 17: Delivery Checklist
Keep the module’s anti-static bag and consumer packaging in their original form until the end of the warranty period. 2.6 System expansion options The number of interfaces routed from the CPC507 module can be increased by installing 2 x XMC/PMC expansion modules. 2.6.1 PMC/XMC Modules... -
Page 18: 2.8 External View And Location Of The Main Elements
CPC507 Operating systems CPC507 is program compatible with the following operating systems: Linux Debian 10; Astra Linux Special Edition, “Smolensk” release v1.5, v1.6; Microsoft Windows 10 IoT Enterprise 64bit; 2.8 External view and location of the main elements The following figures will help you identify the components, understand their relationships and functions. -
Page 19: Figure 1-1: Block Diagram Of Cpc507
CPC507 Figure 2-1: Block diagram of CPC507 CPC507 CPCI 6U Board Block Diagram PCI-E/PCI-X PCI-X PMC1 Connector Bridge P1-P4 64Bit/100Mhz PI7C9x130 XMC1 Connector PCIe x8 Gen3 PMC2 Connector P1-P4 XMC2 Connector PCIe x4 Gen3 Switch HD AUDIO Intel i350 COM0... -
Page 20: Figure 2 2: Location Of The Main Components Of Cpc507, Top View
CPC507 2.8.2 Location of main components Figure 2 2: Location of the main components of CPC507, top view The appearance of the module versions may slightly differ from the one shown in this figure. C P C 5 0 7... -
Page 21: Figure 2 3: Cpc507: Size And Dimensions
CPC507 2.8.3 Size and dimensions Figure 2 3: CPC507: size and dimensions C P C 5 0 7 U s e r M a n u a l... -
Page 22: Functional Description
CPC507 Functional Description 3.1 Specific performance features of functional nodes AMD Ryzen Embedded SoC APU 64-bit AMD CPU, manufactured on the basis of the 14nm technology, with 25W heat dissipation and industrial operating temperature range (from -40 to + 105°C). -
Page 23: 3.2 Module Interfaces
The board has a switch for resetting BIOS settings to default settings. 3.2 Module Interfaces 3.2.1 PMC/XMC interface The top side of the CPC507 board has connectors for PMC/XMC expansion modules, see Figure 2- 2: Location of the main components of CPC507, top view CPC507 supports two XMC/PMC modules: ... -
Page 24: Table 3-1: Purpose Of Xmc1 Xs7 (P15) And Xmc2 Xs8 (P15) Connectors Pins On The Cpc507 Board
XS8 (P15) connectors. Figure 3-1: XMC XS7 (P15) and XS8 (P15) connectors Below you can find the pinout tables for XMC connectors. Table 3-1: Purpose of XMC1 XS7 (P15) and XMC2 XS8 (P15) connectors pins on the CPC507 board RX0+ RX0- +3.3V... -
Page 25: Figure 3-2: Connectors Pmc Xs10 (P1), Xs11 (P3), Xs12 (P2) And Xs13 (P4)
J5 and J3 CompactPCI connectors. The PMC interface complies with the IEEEP1386.1 specification, which defines the PCI electrical interface for the boards of the Common Mezzanine Card (CMC) form-factor. CPC507 allows operation of the 3.3V PCI PMC bus. -
Page 26: Table 3-2: Pmc Connector Pin Assignment
CPC507 Table 3-2: PMC connector pin assignment Number of Number of Number Number of of pin Function Function Function Function XS9(P1)/XS11 XS13(P2)/X XS10(P3)/ XS14(P4)/X (P1) S15(P2) XS12(P3) S16(P4) P1_1 P2_1 +12V P3_1 P4_1 PMC_I/O P1_2 -12V P2_2 P3_2 P4_2 PMC_I/O... -
Page 27: Table 1-1: Assignment Of Sata Xs6 Connector Pins
(XS6); the second interface is used for connection of the integrated SSD. The XS6 connector (located on the top side of the CPC507 board, see Figure 2 2: Location of the main components of CPC507, top view) enables installing a CFast drive on the CPC507 module together with the PMC/XMC expansion module. -
Page 28: Table 3-4: Assignment Of Xp2 Connector Pins
3.2.4 Connectors on the front panel of CPC507 3.2.4.1 USB interfaces CPC507 has 3 x USB 3.0 ports located on the front panel, see Figure 2 4. The following modes are supported: high-speed, full-speed, and low-speed. USB 2.0 in high-speed mode enables data transfer at the rates up to 480 Mb/sec, USB 3.0 - up to 5 Gb/sec. -
Page 29: Table 3-5: Assignment Of Usb Connector Pins On The Front Panel Of Cpc507
CPC507 Table 3-5: Assignment of USB connector pins on the front panel of CPC507 Circuit Function VBus +5V Power USB D- Differential USB- USB D+ Differential USB+ Ground for power return StdA_SSRX- SuperSpeed RX- StdA_SSRX+ SuperSpeed RX+ GND_DRAIN Ground for signal return... - Page 30 CPC507 The green LED is on if a 100 Mb/sec. link is installed, the orange LED is on if a 1000 Mb/sec. link is installed. The yellow “Act” (network activity) LED is on when the computer is receiving or sending packets through the RJ45 connector.
-
Page 31: Table 3-7: Assignment Of Xs1 Displayport Connector Pins Of The Cpc507 Module
CPC507 3.2.4.3 DisplayPort The DisplayPort connector on the front panel of the CPC507 is designed for connecting digital monitors with resolution up to 4096x2160@60Hz. The output also makes it possible to connect DVI-D monitors via a passive adapter. Figure 3-5: DisplayPort connector... -
Page 32: Table 3-8: State Of The Sys Led Of The Cpc507 Module
Blinking red and blue ~1 Hz Processor is executing POST procedures Solid red and blue POST procedure is complete, OS boot is in progress The red GP LED can signal the user about CPC507 module malfunctions CPC507 (see subparagraph 7 : Troubleshooting). - Page 33 3.2.6.5 Power Mode LED (SYS) The red and blue SYS LED on the front panel of the CPC507 is used to indicate the power supply mode of the module, see the table "State of the SYS LED of the CPC507 module" (Table 3-8).
-
Page 34: Figure 3-7: Compactpci Connectors (J1 - J5 In Accordance With The Compactpci Specification)
J4 and J5 provide additional Rear I/O interface functions. The CPC507 module is designed in accordance with the CompactPCI bus architecture. The CompactPCI standard is electrically identical to the PCI local bus, but these systems have been improved, which made them fit for the use in harsh industrial environments with more expansion slots. -
Page 35: Table 3-9: Color Code Designations Of Connectors
5V peripheral cards from being mounted into the sockets designed for 3.3V voltage, and vice versa. The backplane connectors are always labeled in accordance with the signal voltage level (VIO). CPC507 is a board with the signal level of 3.3V / 5V. Table 0-2: Color code designations of connectors Signal voltage Color 3.3 V... -
Page 36: Table 1-2: Assignment Of Pins Of The Compactpci Xs20 System Connector (J1)
CPC507 3.2.7.2 Pin assignment of CompactPCI XS20 and XS18 connectors CPC507 is equipped with two CompactPCI bus connectors. Their pins have a pitch of 22 mm – XS20 and XS18. Table 0-3: Assignment of pins of the CompactPCI XS20 system connector (J1) -
Page 37: Table 1-3: Pin Assignment Of The Xs18 (J2) System Connector Of 64-Bit Compactpci Bus
CPC507 Table 0-4: Pin assignment of the XS18 (J2) system connector of 64-bit CompactPCI bus XS18 CLK6 CLK5 BRSVP2A18 BRSVP2B18 BRSVP2C18 BRSVP2E18 BRSVP2A17 PRST# REQ6# GNT6# BRSVP2A16 BRSVP2B16 DEG# BRSVP2E16 BRSVP2A15 FAL# REQ5# GNT5# AD[35] AD[34] AD[33] AD[32] AD[38] AD[37]... -
Page 38: Table 1-4: Pin Assignment Of The Xs21 (J3) Connector Of Cpc507
The board provides additional options for connecting peripheral I/O devices in compact special- purpose systems. In order to use the Rear I/O board, a special backplane is required. The CPC507 board and its XS21, XS19 and XS17 connectors are compatible with all standard 6U CompactPCI backplanes with I/O support through the corresponding connectors in the system slot. -
Page 39: Table 3-13: Assignment Of The Xs19 (J4) Connector Pins Of The Cpc507 Module
CPC507 Table 0-6: Assignment of the XS19 (J4) connector pins of the CPC507 module XS19 DP1_HPD DP1_LANE0+ DP1_LANE0- LAN_LED0 DP1_LANE1+ DP1_LANE1- LAN_LED1 DP1_LANE2+ DP1_LANE2- LAN_LED2 DP1_LANE3+ DP1_LANE3- LAN_LED3 DP1_AUX- DP1_AUX+ DP_CTRL_DAT DP2_HPD DP3_LANE0+ DP3_LANE0- DP2_LANE0+ DP2_LANE0- DP3_LANE1+ DP3_LANE1- DP2_LANE1+ DP2_LANE1-... -
Page 40: Table 3-14: Assignment Of The Xs17 (J5) Connector Pins Of Cpc507
CPC507 Table 0-7: Assignment of the XS17 (J5) connector pins of CPC507 XS17 LPC_AD0 LPCCLK +3.3V LPC_AD1 SIOCLK +3.3V LPC_AD2 SUSCLK +3.3V USB1_DP USB1_DM LPC_AD3 SERIRQ USB3_DP USB3_DM LPC_FRAME# LPC_RST# USB0_DP USB0_DM ETH_MDI1+ ETH_MDI1- ETH_MDI3+ ETH_MDI3- ETH_MDI0+ ETH_MDI0- ETH_MDI2+ ETH_MDI2-... -
Page 41: Timers
CPC507 Timers The module is equipped with the following timers: RTC (Real-Time Clock) PCH includes a battery powered real time clock. Watchdog Timer See the description below. 3.3.1 Watchdog Timer The watchdog timer is implemented in the FPGA as a device based on the LPC bus. The watchdog timer is enabled and the hardware interrupt (IRQ) is selected in the BIOS Setup. - Page 42 CPC507 Description of I/O registers of WDT controller Timer Current Value Register [23:0] Base+0h Name Description Write/Read: Timer_Current_Value[7:0] Bits 7:0 of the counter initial value Base+1h Name Description Write/Read: Timer_Current_Value[15:8] Bits 15:8 of the counter initial value Base+2h Name Description...
- Page 43 CPC507 Status Register Base+6h Name Description Reserved Write/Read: Second timeout flag. It is set to “1” if TMF = 1. This flag initiates an interrupt. If the board reset is enabled RSTE = 1, a hardware reset is carried out. Can be reset by writing “1”...
-
Page 44: Spi Controller / Leds / Gpio
CPC507 SPI controller / LEDs / GPIO 3.4.1 Description of SPI controller registers Table 0-8: Registers of the SPI controller I/O port address Type HARD RESET Configuration register Base+0 FRAM address value [7:0] Base+1 FRAM address value [14:8] Base+2 SPI data value [7:0]... - Page 45 CPC507 3.4.2 Programming the SPI device The work with FRAM is carried out in the I/O area at addresses 310h-313h. Writing data byte (32h) to FRAM at the address (144h) DX, 310H AL, 44H DX, AL DX, 311H AL, 01H...
-
Page 46: Devices On The Local Smbus
PCI-E Bridge Compact PCI PCI-E Bridge PMC Battery The CPC507 uses one 3.0 V lithium battery to power the real time clock. NAND drive The module has an integrated 32 GB SSD. The drive is connected to the SATA0 interface. -
Page 47: Installation
Please refer to the documentation attached to your operating system. Safety requirements When handling CPC507, you should strictly follow the safety requirements listed below. The manufacturer – Fastwel Group, is not responsible for any damages resulting from noncompliance with these requirements. -
Page 48: Cpc507 Installation Procedure
CPC507 CPC507 installation procedure The below procedure refers to the installing the CPC507 into the system. The removal procedure is described in other chapters. In order to install the board into the system, follow the below procedure: Make sure that the safety requirements listed in chapter 4.1 have been observed. -
Page 49: Board Removal Procedure
Installing peripherals to CPC507 A wide range of peripheral devices can be connected to the CPC507, where their installation methods can vary greatly. The following sections contain general installation instructions rather than detailed algorithms. -
Page 50: Battery Replacement
Installing CFast Drive This subparagraph is used to describe how to install a CFast drive on the CPC507 module. The CFast drive is plugged into the XS6 connector. It is possible to install the drive together with the PMC/XMC expansion module. -
Page 51: System Setup
(factory defaults) if the system does not boot (e.g. due to the BIOS setup errors or invalid password). In order to reset the BIOS parameters of the CPC507 module, the sequence of actions should be as follows: De-energize the system;... -
Page 52: Ami Aptio Bios Setup
CPC507 AMI Aptio BIOS Setup Starting and Updating BIOS Setup An adapted version of the Aptio TSE (Text Setup Environment) BIOS is installed on your computer, which is the standard system for IBM PC AT-compatible computers. It supports Intel® x86 and compatible processors and provides low-level support for processor, memory, and I/O subsystems. - Page 53 CPC507 Using this key the user can load the previous value into TSE. With this key, the user can load the optimum default settings into TSE. With this key, user can save current settings and exit the TSE. The <ESC> key enables you to discard the changes made and exit Aptio TSE.
-
Page 54: Advanced
CPC507 Advanced The tab is used for making additional module settings. 6.2.1 Fastwel Features This tab is used for configuring module’s devices. Function Purpose Default value Operation mode of the board’s Ejector switch function Disabled [PWR Button+Reset/ PWR ejector switch. -
Page 55: Troubleshooting
CPC507 CPC507 Troubleshooting Before contacting the service center, please read the troubleshooting information, since the problem may not be related to the device failure. Table 0-10: CPC507 fault causes and their rectifications Issue Cause Rectification The board does not There are no supply... -
Page 56: Power Consumption
CPC507 Power Consumption The CPC507 module is designed with due consideration of the optimum power consumption and distribution. However, we should pay attention to certain requirements that are vital to ensure stability and reliability. The table below shows the values of the maximum allowable voltages on the power lines, which, if exceeded, can result in module damages. -
Page 57: Influence Of External Factors
Number of shocks 1000 * For commercial version. The mean time between failures (MTBF) of CPC507 is no less than 50,000 hours. © 2 0 2 1 F a s t w e l V e r . 0 0 1... -
Page 58: Annex A: Terms, Acronyms And Abbreviations
CPC507 ANNEX A Table A 1 – Terms, acronyms and abbreviations Term Value ACPI Advanced Configuration and Power Interface Accelerated Graphics Port AGTL Advanced Gunning Transceiver Logic BIOS Basic Input-Output System Baseboard Management Controller cPCI CompactPCI CRT-display Cathode Ray Tube Display... - Page 59 CPC507 Liquid crystal display Low Pin Count LVDS Low Voltage Differential Signal NAND Flash Not And (electronic logic gate) Media Dependent Interface Personal Computer Programmed Input/Output PLCC Plastic Leaded Chip Carrier Peripheral Management Controller POST Power On Self Test Processor System Bus...
-
Page 60: Annex B: Dicslaimer
1.2 Use of the Fastwel products as well as the objects of intellectual property containing in them, in the ways and for the purposes, not provided by the present user manual and datasheet isn't allowed without preliminary written approval of Fastwel.
