JBL HTI8 Series Technical Manual

Technical Manual
HTI8
Home Theater Series
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Grille
• Low-Frequency Transducer
DC Resistance
• High-Frequency Transducer 1" (25mm) pure-titanium
DC Resistance
• Crossover Network
PACKING
12
11
9
JBL Consumer Products, 250 Crossways Park Drive, Woodbury, New York 11797
8 ohms
120 watts*
30Hz – 20kHz (–10dB)
90dB (2.83V @ 1 meter)
2.5kHz
590-0104
8" (200mm) polymer-coated
aluminum cone w/rubber
surround
(330-0137)
5.2 ohms ±10%
dome, w/swivel mount
(300-0078)
6.1 ohms ±10%
340-0227
13
10
LEGEND ON PAGE 2
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Plate Size (W x H)
• Mounting Cutout
Size (W x H)
• Mounting Depth
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
WIRING DIAGRAM
NETWORK
340-0227
340-0227
HTi8 SCHEMATIC
L1
0.6mH
+
C1
INPUTS
16uF
100V
-
C3
3uF
250V
L2
0.5mH
6.0V input 30Hz – 20kHz
5.0V input 30Hz – 3kHz
2.83V input 2kHz – 20kHz
10-1/8" x 13-1/8" (257mm x 333mm)
8-7/8" x 11-13/16" (225mm x 300mm)
4" (100mm)
12 lbs/5.4kg sold in pairs
LOW-
FREQUENCY
TRANSDUCER
330-0137
GREEN +
BLACK -
HIGH-
FREQUENCY
TRANSDUCER
300-0078
BLACK +
YELLOW -
L3
0.6mH
GREEN
.250 +
C2
20uF
100V
L.F.
R1
7.5 ohms
5 watts
BLACK
.205 -
C4
R2
3uF
1.2 ohms
250V
5 watts
BLACK .110
H.F.
YEL
.110
Rev 2 2/06
-
+
