CHERUBINI BLUE BUS Instructions Manual

Control and centralization module for rolling shutters
Table of Contents

Advertisement

Quick Links

A510023
BLUE BUS
A510024
BLUE BUS RX
MODULO DI COMANDO E CENTRALIZZAZIONE
I
PER AVVOLGIBILI
CONTROL AND CENTRALIZATION MODULE
GB
FOR ROLLING SHUTTERS
STEUER- UND ZENTRALISIERUNGSMODUL
D
FÜR ROLLLADEN
MODULE DE COMMANDE ET DE CENTRALISATION
F
POUR VOLETS ENROULABLES
MÓDULO DE MANDO Y CENTRALIZACIÓN
E
PARA PERSIANAS ENROLLABLES
ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
INSTRUCTIONS - INSTRUCCIONES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLUE BUS and is the answer not in the manual?

Questions and answers

Summary of Contents for CHERUBINI BLUE BUS

  • Page 1 A510023 BLUE BUS A510024 BLUE BUS RX MODULO DI COMANDO E CENTRALIZZAZIONE PER AVVOLGIBILI CONTROL AND CENTRALIZATION MODULE FOR ROLLING SHUTTERS STEUER- UND ZENTRALISIERUNGSMODUL FÜR ROLLLADEN MODULE DE COMMANDE ET DE CENTRALISATION POUR VOLETS ENROULABLES MÓDULO DE MANDO Y CENTRALIZACIÓN...
  • Page 3: Table Of Contents

    ..................p. 40 - Centralization of Blue Bus modules in a sequence with a 2-wire bus for white wire motors p. 41 - Centralization with a Blue Bus module and A510008 expansion modules ......p. 42 - Guarantee ..........................
  • Page 4: Product Features

    PRODUCT FEATURES The Blue Bus control and centralisation module is indicated for the control of Cherubini mechanical and electronic motors intended for rolling shutters applications. ELECTRICAL CONNECTIONS RESET/AUX MOTOR MOTORE CENTR CMD LOC CMD SENSOR NC/NO SEQ IN SEQ OUT...
  • Page 5: Legend

    Press button A - long motor rotation in other direction Press buttons A and B at the same time - double short rotation COMPATIBLE REMOTE CONTROLS (BLUE BUS RX) display - Skipper LED - Skipper channel selector stop Skipper down...
  • Page 6: Key To Symbols On The Control Switch

    SEQ IN SEQ OUT SEQ IN SEQ OUT Note: centralised control is transmitted from one Blue Bus module to the other by the Cherubini 2-wire BUS. Maximum length of the wire from one card to the other Unshielded wire 10 m...
  • Page 7: Blue Bus Module Connection To Motors With Standard Wiring

    Note 1: for complete installation examples refer to the diagrams at the back of the manual. Note 2: the the output connection from L1 is used to propagate the centralised control and the alarms signals through the Cherubini 2-wire BUS for the purposes of motor movement.
  • Page 8: Commands From A Remote Control (Blue Bus Rx)

    COMMANDS FROM A REMOTE CONTROL (BLUE BUS RX) It is possible to control the Blue Bus RX control unit by means of a Cherubini remote control. Follow the instructions shown in the following pages for programming. As far as all programming sequences are concerned, we recommend also consulting the remote control instruction leaflet.
  • Page 9: Function Open/Close Programming Remote Control Skipper

    FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER PLUS - SKIPPER LUX - SKIPPER P-LUX To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).
  • Page 10 FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER - SKIPPER WALL To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).
  • Page 11: Setting The First Remote Control (Blue Bus Rx)

    SETTING THE FIRST REMOTE CONTROL (BLUE BUS RX) This operation can only be performed when the control unit is new, or after a total delete of the memory. During this step, power up only one control unit at time! T1: First remote control to be set.
  • Page 12: Setting Of Additional Remote Controls (Blue Bus Rx)

    SETTING OF ADDITIONAL REMOTE CONTROLS (BLUE BUS RX) Up to 15 remote controls can be set. Tn: Already programmed remote control Tx: Additional remote control Tx (2 sec) REMOTE CONTROL MEMORY CLEARING (BLUE BUS RX) It is possible to delete each memorized remote control individually. As the last one is deleted the control unit initial condition is restored.
  • Page 13: Special Function (Blue Bus Rx): Short-Term Setting Of A Remote Control

    SPECIAL FUNCTIONS (BLUE BUS RX) SHORT-TERM SETTING OF A REMOTE CONTROL This function makes it possible to store a remote control temporarily, for example, with the purpose of setting the limit switches during assembly in the factory. A later final saving of the remote control will be possible using the appropriate command sequence (see: “SETTING THE FIRST REMOTE CONTROL”).
  • Page 14: Configuration Of The Blue Bus Module

    CONFIGURATION OF THE BLUE BUS MODULE The Dip Switch present on the module makes it possible to configure some functions. Configurating the local command and setting the type of motor Motor command “dead man” The motor operates in the “dead man mode”. This...
  • Page 15: Configuration Of The Auxiliary "Sensor" Input

    J3 connector of the control unit, by means of three wires (up, down, common) or by using a remote control, if the module is of the Blue Bus RX type. By pressing one of the LOC CMD push buttons, the motor moves in the desired direction, until the limit switch is reached and stops according to the settings of Dip Switch 1 and 2.
  • Page 16: Operation Of Centralized Commands

    Otherwise it is possible to centralize modules in a sequence using the CHERUBINI 2-wire BUS present on the J2 connector. Centralized commands are delayed by 1 second, have priority over local commands, can move the...
  • Page 17: Special Commands (Using Blue Tronic Rx V32)

    SPECIAL COMMANDS (using BLUE TRONIC RX V32) If the module is connected with a Blue Tronic RX V32 motor, it is possible to control the start of the tilting mode and to determine its orientation according to the settings of DIP switch 1 and Dip Switch 2.
  • Page 18 CONFIGURATION OF THE PERSYROLL/SOLOMATIC TILTING MODE START DSW3 ON DSW1 OFF CENTR CMD DSW2 ON Tilting stop mode DOWN start DSW3 OFF 10 sec Sequence 0.5 sec stop IN THE TILTING MODE: ADJUSTMENT OF THE SLATS CENTR CMD Smaller DSW3 ON opening of DSW1 OFF the slats...
  • Page 19: Special Commands (Using Modules A510008)

    SPECIAL COMMANDS (using MODULES A510008) This operation mode is useful when one intends to use the Blue Bus module to control one or more Cherubini A510008 expansion modules (see, for example, connection on page 42). The Blue Bus module is equipped with a current sensor able to manage switching off the exits when the connected motor reaches the limit switch or stops because of an obstacle.
  • Page 23: Guarantee

    GARANZIA La garanzia è di 24 mesi dalla data di fabbricazione apposta all’interno. Durante tale periodo se l’apparecchiatura non funziona correttamente a causa di un componente difettoso, essa verrà riparata o sostituita a discrezione del fabbricante. La garanzia non copre l’integrità del contenitore plastico. La garanzia viene prestata presso la sede del fabbricante.
  • Page 24 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.

This manual is also suitable for:

Blue bus rxA510023A510024
