Thru-the-Wall
Room Air Conditioner
with optional Electric Heat
Contents
IMPORTANT NOTE TO THE OWNER ........................... 2
IMPORTANT NOTE TO THE SERVICER ....................... 2
Unit Features ................................................................ 2
Transportation Damage .............................................. 2
Unpacking The Unit ..................................................... 2
Parts Supplied ............................................................. 2
Unit Accessories ........................................................... 3
Operating Instructions ................................................. 3
Installation Instructions ............................................... 3
Wiring ........................................................................... 6
Unit Operation ............................................................. 6
Preventative Maintenance .......................................... 8
Normal Operating Sounds and Conditions ................ 9
Obtaining Service ........................................................ 9
Warranty ..................................................................... 10
ATTENTION INSTALLING PERSONNEL
As a professional installer you have an obligation to
know the product better than the customer. This
includes all safety precautions and related items.
Prior to actual installation, thoroughly familiarize
yourself with this Instruction Manual. Pay special
attention to all safety warnings. Often during
installation or repair it is possible to place yourself
in a position which is more hazardous than when
the unit is in operation.
IO-291
RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION.
Installation Instructions
and Owner's Manual
This manual must be left with the owner
of the equipment.
WARNING
HIGH VOLTAGE!
Disconnect ALL power before servicing
or installing. Multiple power sources may
be present. Failure to do so may cause
property damage, personal injury, or death.
Remember, it is your responsibility to install the
product safely and to know it well enough to be able
to instruct a customer in its safe use.
Safety is a matter of common sense...a matter of
thinking before acting. Most dealers have a list of
specific good safety practices...follow them.
The precautions listed in this Installation Manual
are intended as supplemental to existing practices.
However, if there is a direct conflict between existing
practices and the content of this manual, the
precautions listed here take precedence.
March 2006
Advertisement
Table of Contents
Related Manuals for Amana PBC123B00MB
Summary of Contents for Amana PBC123B00MB
-
Page 1: Table Of Contents
Thru-the-Wall Room Air Conditioner with optional Electric Heat Contents IMPORTANT NOTE TO THE OWNER ... 2 IMPORTANT NOTE TO THE SERVICER ... 2 Unit Features ... 2 Transportation Damage ... 2 Unpacking The Unit ... 2 Parts Supplied ... 2 Unit Accessories ... -
Page 2: Important Note To The Owner
TWKGSLV rear louver panel kit, a TWEAK2 or TWFAK2 adapter kit is required. ® If the sleeve is an Amana brand wall sleeve, use the TWKGSLV rear louver panel kit. If the sleeve is an Emerson... -
Page 3: Installation Instructions
REAR LOUVER PANEL A TWKGSLV rear louver panel kit is required for unit ® installation into an existing Amana TWEAK2 or TWFAK2 adapter kit is required for unit instal- lation into an existing 27” wall sleeve. The rear louver panel directs air flow for proper unit operation and protects the outdoor coil. - Page 4 Figure 3 3. Remove shipping pads inside air conditioner next to compressor. (See Figure B.) Figure B 4. Carefully slide the chassis into the sleeve. Ensure that the ground wire is not pinched or in the path of the condenser fan. 5.
- Page 5 To replace front grille: Hook the tabs on the front grille even with the tabs on the case and snap into place. Replace the screws and filter. Refer to Page 4, Figure A. VENT CONTROL AND AIR DIRECTION (See Figure E) The vent control is located behind the front grille on the right side of the air discharge area.
-
Page 6: Wiring
Remove the front grille to adjust the vertical louvers side-to- side to direct the air left or right. DISCHARGE AIR GRILLE Figure 5 IMPORTANT NOTES: 1. The unit is equipped with a rubber-grommet-mounted compressor. These grommets are factory set and require no adjustment. -
Page 7: Unit Operation
VOLTAGE MEASUREMENTS Before connecting the unit, measure the supply voltage. Voltage must fall within the voltage utilization range given in Table 1. Operating Voltage Unit Voltage Voltage Utilization Range Rating Minimum 230/208 Table 1 Operating Voltage Unit Operation COOLING MODELS - PBC Figure 6 Two rotary knobs (Figure 6) control temperature and opera- tional modes. -
Page 8: Preventative Maintenance
Wait 3 minutes to restart 70° HIGH HEAT HEAT 55° 85° WARMER COOLER LOW HEAT On low heat, the fan runs at its lowest speed and provides the quietest fan operation. In this mode the electric heater cycles on and off by thermostat. Wait 3 minutes to restart 70°... -
Page 9: Normal Operating Sounds And Conditions
COMPRESSOR The compressor is hermetically sealed, permanently lubri- cated and requires no additional oiling. FRONT PANEL AND GRILLE The front panel and grille can be cleaned with a mild soap or detergent. Do not use hydrocarbon-based cleaners (e.g. acetone, benzene, naphtha, gasoline, etc.) to clean the front panel or grille.
