SERVICE
WASHING MACHINE (DRUM)
Refer to the service manual in the GSPN (see the rear cover) for the more information.
WASHING MACHINE
DRUM TYPE
Basic Model : WF856UHSAGD/SA
(SEINE PROJECT)
Model Name : WF706U2SA*
(SEINE PROJECT)
Model Code : WF706U2SAWQ/TL
(SEINE PROJECT)
Manual
1. Safety Instructions
2. Features and Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. PCB Diagram
6. Wiring Diagram
7. Schematic Diagram
8. Reference
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF706U2SA Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung WF706U2SA Series

Summary of Contents for Samsung WF706U2SA Series

  • Page 1 WASHING MACHINE DRUM TYPE Basic Model : WF856UHSAGD/SA (SEINE PROJECT) Model Name : WF706U2SA* (SEINE PROJECT) Model Code : WF706U2SAWQ/TL (SEINE PROJECT) SERVICE Manual WASHING MACHINE (DRUM) CONTENTS 1. Safety Instructions 2. Features and Specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. PCB Diagram 6.

  • Page 2: Table Of Contents

    CONTENTS 1. Safety instructions ..............1 1-1.

  • Page 3: Safety Instructions

    1. Safety InStructIonS 1-1. Safety InStructIonS for ServIce engIneerS ► Make sure to observe the following instructions to operate the product correctly and safely and prevent possible accidents and hazards while servicing. ► Two types of safety symbols, Warning and Caution, are used in the safety instructions. Hazards or unsafe practices that may result in severe personal injury or death. WarnIng Hazards or unsafe practices that may result in minor personal injury or property damage. cautIon WarnIng Before ServIcIng...
  • Page 4 WarnIng WHILe ServIcIng • Check if the power plug and outlet are damaged, flattened, cut or otherwise degraded. √ If faulty, replace it immediately. Failing to do so may result in electric shock or fire. • Completely remove any dust or foreign material from the housing, wiring and connection parts. √ This will prevent a risk of fire due to tracking and shorts in advance. • When connecting wires, make sure to connect them using the relevant connectors and check that they are completely connected. √ If tape is used instead of the connectors, it may cause fire due to tracking. • Make sure to discharge the PBA power terminals before starting the service. √ Failing to do so may result in a high voltage electric shock. • When replacing the heater, make sure to fasten the nut after ensuring that it is inserted into the bracket-heater. √ If not inserted into the bracket-heater, it touches the drum and causes noise and electric leakage. WarnIng after ServIcIng • Check the wiring. √ Ensure that no wire touches a rotating part or a sharpened part of the electrical harness. • Check for any water leakage. √ Perform a test run for the washing machine using the standard course and check whether there is any water leakage through the floor section or the pipes. • Do not allow consumers to repair or service any part of the washing machine themselves. √ This may result in personal injury and shorten the product lifetime.
  • Page 5 cautIon Before ServIcIng • Do not sprinkle water onto the washing machine directly when cleaning it. √ This may result in electric shock or fire, and may shorten the product lifetime. • Do not place any containers with water on the washing machine. √ If the water is spilled, it may result in electric shock or fire. This will also shorten the product lifetime. • Do not install the washing machine in a location exposed to snow or rain. √ This may result in electric shock or fire, and shorten the product lifetime. • Do not press a control button using a sharp tool or object. √ This may result in electric shock or damage to the product. cautIon WHILe ServIcIng • When wiring a harness, make sure to seal it completely so no liquid can enter. √ Make sure that they do not break when force is exerted. • Check if there is any residue that shows that liquid entered the electric parts or harnesses. √ If any liquid has entered into a part, replace it or completely remove any remaining moisture from it. • If you need to place the washing machine on its back for servicing purposes, place a support(s) on the floor and lay it down carefully so its side is on the floor. √ Do not lay it down on its front. This may result in the inside tub damaging parts. Safety Instructions _ 3...
  • Page 6 cautIon after ServIcIng • Check the assembled status of the parts. √ They must be the same as before servicing. • Check the insulation resistance. √ Disconnect the power cord from the power outlet and measure the insulation resistance between the power plug and the grounding wire of the washing machine. The value must be greater than 10MΩ when measured with a 500V DC Megger. • Check whether the washing machine is level in relationship with the floor. Check whether it is installed firmly on the floor. √ Vibrations can shorten the lifetime of the product. 4 _ Safety Instructions...

  • Page 7: Features And Specifications

    2. Features and speciFications 2-1. Features ■ common Features Features Description Big Door • This is the maximum capacity to be implemented at the standard 55 cm depth. - The benefits for customers have been greatly increased due to the efficient use of limited space. - Usability has been improved due to the easier loading and removing of the laundry. • The size of the loading entry has increased: 300 mm → 308 mm (Wide) - A lot more washing can be conveniently added and removed. 308 mm Diamond Drum • The washing performance has increased but potential damage to the washing has been minimized. (The size of the holes on the diamond drum has been reduced for minimizing damage to the washing.) - The embossed wall of the drum serves as a washboard, dramatically increasing the washing performance compared with existing drum washing machines, which use the power of the difference in elevation only. - The size of holes has been reduced drastically, maintaining the optimal wash performance (Washing Cost 1.0) while saving on water and electricity required for washing. - The structure of the holes on the diamond drum has been changed minimizing potential damage to the washing since it is difficult for strands to enter the holes.
  • Page 8 ■ common Features Features Description Bubble Wash • Bubble Cushion - Eco Bubble technology activates the detergent much earlier and faster in the wash cycle by use of a Bubble Generator, rapidly mixing a small amount of water with air and detergent (works with powder, tabs or liquid detergents). This creates a foam cushion in the drum ahead of introducing the main water intake. • Super energy saving - the detergent infused bubbles penetrate the fabrics much faster and efficiently than for a conventional wash system, delivering a cleaner wash performance especially for colder temperature cycles. The lower the water temperature of the cycle, the greater the impact of using Eco Bubble versus conventional systems, this allowing more use of colder wash cycles and helping to save energy beyond the A+++ energy rating of this appliance. • No detergent remainning - the detergent disslove completely in a very short time while wash begin by bubble wash technology,so don’t afraid of detergent remainnin. 6 _ Features and Specifications...
  • Page 9 ■ optional Features ► The features below depend on the model. Features Description Air Refresh System • Sterilization/Deodorization/Removal of Ticks without Water Washing (Air Washing Using Air and Heating) - Destroying bacteria and ticks without the use of water - Removing the sweat and dirt odors - Maintaining the shape and color of the washing without dry-cleaning • Washing with air. - Removing odors by heating, keeping the washing as new. - Washing with air conveniently, compared with dry-cleaning The goal of deodorization is 60 percent. (40-minute cycle) • Washing one or two shirts in 30 minutes - If a piece of clothes is not completely dry when it is humid, the machine can dry it within 30 minutes • Preventing bio-film caused by humidity from occurring - You do not need to worry about the humidity inside the drum. - The drum is dried regularly, preventing bio-film. Water Safety System • The Water Safety System has invented for perfect leakage protection. The double safety valve connects directly to the water faucet. In the event of a leakage, the built-in sensor immediately detects the leak within a few short seconds, automatically turning off both the water supply and the washing machine.
  • Page 10 ► The features below depend on the model. Features Description Silver Wash System • Samsung’s unique technology generates silver ions that remove bacteria and fungi, and create an invisible shield that protects your clothes from unwanted odors until your next wash. Using an ancient and proven purification technique so simple, yet so advanced it removes microbes even in cold water. • Effect of Silver Wash System - Keeps Stored Clothes Fresh The Ag+ Silver (Nano) Technology anti-bacterial effect keeps fabric free from odor-causing micro-organisms for up to one month, without the use of strong chemical cleaners. There’s no need to worry about musty-smelling clothes even if they remain unused for a long period. - Makes Shapeless Garments a Thing of the Past High temperatures and harsh bleaches can damage and discolor your clothes. The Ag+ Silver (Nano) Technology helps your clothes last longer, without stretching, shrinking, pilling or fading. ceramic Heater • The ceramic heater in Samsung washing machine prevents metals in hard water from being attach to the heater, which may cause a reduction in heater efficiency. It saves energy, time and costs. - Energy Savings Over time, conventional heaters increase their power consumption an average of 5.8 percent, while ceramic heaters only become 1.8 percent less efficient. - Time Savings After three years, conventional heaters take 7.5 percent longer to heat up, whereas ceramic only lose 2.5 percent longer to heat up, whereas ceramic only lose 2.5 percent of their ability to heat up. 10 Years...
  • Page 11 Wool Mark • Fabric Care - Minimize shrinking - Gently and carefully cleans - delicate fabrics that are usually washed by hand. Normal vs Wool mark Normal vs Wool mark Volt Control • The solution for more Durable and Reliable Washing Machine - Although you may not see the direct problems of power surges that run through your electronic devices, a real danger in sudden surges of voltage does exist and this definitely affects your washing machine. This is especially true for machines that require a lot of energy. Samsung’s Volt Control guarantees that your washing machine works safely even with voltage deviations of ±25%. • What does the “Volt Control” mean? - This is technology that allows to safe a washing machine from high shock and even lower voltage. There is an additional protective measure in a washing machine for your precious clothes. It constantly controls washing cycle in a fluctuated situation and re-start automatically when the standard voltage flows back again. 400V 350V 300V...

  • Page 12: Specifications

    2-2. speciFications Model WF706U2SA× Wash Type FRONT LOADING TYPE Dimension 600mm x 550mm x 850mm Water Pressure 50 kPa ~ 800 kPa Annual water consumption (AW_c)2) 9400 ℓ/yr Weight 61 kg Wash & Spin Capacity 7.0 kg Power WASHING and 220-240 V 2000-2400 W Consumption HEATING Spin Revolution max rpm 1200 10 _ Features and Specifications...

  • Page 13: Comparing Specifications With Existing Models

    2-3. CoMPARING SPECIFICATIoNS WITH ExISTING MoDElS (★) : Functions may be different depending on the model. Project senie senie Grade Best Best Model Name WF706U2SA× WF856UHSAGD Image Capacity 7.0 kg 8.5 kg Drum Volume 9400 ℓ/yr 64 ℓ Max Rpm 1400 1400 Motor BLDC BLDC Control Sys Fuzzy logic Fuzzy logic Weight Detection 3 Stages 3 Stages Main Heater Capacity 2000 W / 230 V 2000 W / 230 V Spec Water Supply Cold only...

  • Page 14: Options Specifications

    2-5. oPTIoNS SPECIFICATIoNS item Code Remarks BOLT-SPANER DC60-40146A Default ★ For specific HOSE-WATER DC62-10289C ★ models only HOSE-WATER For specific DC62-00079A ★ (AQUA-STOP) models only MANUAL-USERS DC68-03178F Default CAP-FIXER DC67-00307A Default HOSE-HANGER DC62-10278A Default ★ Note • (★) is supplied for specific models only among those without water supply hoses. • You can purchase additional water supply and drain hoses from a service center. • For built-in models, the spanner, water supply and drain hoses are not supplied. Both the water supply and drain hoses are supplied during the installation. 12 _ Features and Specifications...

  • Page 15: Disassembly And Reassembly

    3. Disassembly anD Reassembly 3-1. Tools foR Disassembly anD Reassembly Tool Type Remarks Heater(1),Tub(12), Fixer 10mm screw(5), Motor(2), Balance(9) Shock Absorber (2 holes Box driver 13mm each in left/right), Damper(2), Damper(friction 2) 19mm Pulley(1) 10mm Double- ended 13mm Replaced by box driver spanner 19mm A Tool for protecting empty...

  • Page 16: Standard Disassembly Drawings

    3-2. sTanDaRD Disassembly DRawings ► This is a standard disassembly diagram and may differ from the actual product. Use this material as a reference when disassembling and reassembling the product. Part Description Figure ASSY 1. Remove the two screws COVER holding the Top Cover at the back of the unit. 2. Remove the top-cover by lifting it up after pulling it back about 15mm. 3. Then, the Water (Pressure) Water valve Noise filter Sensor, Noise Filter and Water Valve can be replaced. Sensor pressure 14 _ Removal and Reassembly...
  • Page 17 Part Description Figure ASSY 1. Remove the 2 screws hoding PANEL the front operating panel. CONTROL 2. Remove the two screws at the top of the ASSY-PANEL CONTROL. 3. Hold the ASSY-PANEL CONTROL while pulling it upwards and release the hook to remove it. 4. Disconnect the terminals connected to the PCB by hand. 5. H old the ASSY-PANEL CONTROL while pulling it upwards and release the hook to remove it.
  • Page 18 Part name Description Figure SUB-PCB 1.There are six clasps to fix pcb, such as the right picture ③ ③ shows. ④ ① ② ② 2.Press the clasp ①,release the clasp ①,and then press clasp the clasp ②,release ②,after that press clasp ③ release the clasp from ③...
  • Page 19 Part Description Figuer WATER 1. Remove the top-cover. SUPPLY VALVE 2. Separate the water supply valve wire. 3. Remove the 2 screws holding the water supply valve. Removal and Reassembly _ 17...
  • Page 20 Part Description Figure SENSOR 1. Connect the Water-Hose PRESSURE to the main body of the Pressure-Switch. 2. Fix the Hose-Clamper. 3. Place the Pressure-Switch into the Bracket Hole holding the main body of the Pressure-Switch. 4. To separate the Pressure- Switch, pull the Pressure- Switch forwards while pushing the marked part with your finger. 18 _ Removal and Reassembly...
  • Page 21 NO. Part name Description Figure NOISE 1. Seperate top cover. FILTER 2. Seperate filter net wire. 3. Remove the nut. 4. Replace filter net. DOOR HINGE 1. Open the door,removing the two screws holding the door hinge and sep- erate the door 2. Remove the 11 screws holding the Holder Glass, separate the Holder Glass and replace the hinge.
  • Page 22 NO. Part name Description Figure DOOR-LOCK 1.Open the Door. 2.Remove the Wire Dia- phragm and remove it from The Front Frame. For easier disassem- bly, remove the spring from the lower part of the Diaphragm with a (-) screwdriver. Since the Diaphragm can be damaged when removing it, remove it slowly in one direction.
  • Page 23 Part Description Figure FRAME 1. Remove the two screws FRONT holding the frame-front. 2. Remove the three screws holding the bottom of the frame-front. 3. The door-diaphragm, pump, shock- damper and door lock switch. Removal and Reassembly _ 21...
  • Page 24 Part Description Figure COVER- 1. Remove the 4 screws holding BACK the Back-Cover at the back of the washing machine. BELT 1. Separate the belt and then assembly it. 2. Check if the belt position is at the center of the Pulley. Assembling the belt Place the belt around the Pulley ( ) and then over the Motor-Pulley ( ). MOTOR 1. Separate the Wire Housing from the motor. 2. Remove the two bolts holding the motor at the back of the washing machine.
  • Page 25 No. Part name Description Figure 1.Insert the (-) screw or BUBBLE coin driver into the upper PUMP AND part of the Filter Cover DRAIN PUMP and push it downwards to release the catch. 2.Remove the remaining water through the drain- age hose. Place a bowl under the drainage hose, or the remaining water may fl ow out.
  • Page 26 No. Part name Description Figure BUBBLE 6.Release the clamper PUMP AND hose which con- DRAIN PUMP nected pump and hose drain,then seperate it. 7.Disconnect the terminal of wires. 8.Remove 3 screws as photograph, then sep- erate pump drain and replace it. ※Check Points for Troubleshooting 1.Separate the Drain Filter and check if any alien substances are inside the pump (e.g. coins, buttons .., etc.) → Remove these if found.
  • Page 27 No. Part name Description Figure DAMPER 1. Remove the top screw shown in the figure from back. 2. Remove the following screw shown in the figure from front. Seprate the damper. Removal and Reassembly _ 25...
  • Page 28 Part name Description Figure WEIGHT- 1.Remove the three screws. BALANCE 3.Remove the three screws. 4.Separate the WEIGHT- BALANCE(F). For disassembly, please make sure assembled the BRACKET-NUT into the TUB first. Make sure the hole and hole respond to each other correctly. There is no ringt and left direction for WEIGHT- BALANCE(F). 26 _ Removal and Reassembly...
  • Page 29 Part name Description Figure HOSE-FILTER 1.Disassembling and Reassembling the Hose- Joint Clamper 1. Separate the Back HEATER Cover. 2. Separate the Connection Housing (3). 3. Remove the nut and the screw holding the cover- heater. Separate the cover-heater. Removal and Reassembly _ 27...
  • Page 30 Part Description Figure HEATER 4. Remove the nut holding the heater 5. Remove the Heater from the Tub. Caution Make sure to insert the Heater into the correct position of the bracket inside the Tub when reassembling it. Otherwise, there is a danger of a fire. Make sure to push it inwards until the packing part comes into the Tub completely when reassembling it so that the packing part is completely stuck to the Tub.
  • Page 31 Part name Description Figure SPRING- 1. Insert the vertical hook of SPRINGHANGER into the HINGER GUIDE-SPRING on the ASSY-FRAME. 2.Drag the SPRING-HANGER to insert the elliptical hook into the hole that’s at the side of the ASSY-TUB as the left picture show.
  • Page 32 Part Description Figure ASSY-TUB 1. Remove the 14 screws holding the tub . 2. Separate the ASSY-BOLT on the BACK-TUB. 3. Separate the PULLEY. 4. Separate the ASSY DRUM. PACKING- 1. Assemble packing-tub’s one side of “凹” to TUB-BACK use two hands. 30 _ Removal and Reassembly...
  • Page 33 Part Description Figure OIL-SEAL 1. Assemble the OIL-SEAL in the TUB-BACK. 2. Press the OIL-SEAL gently and turn it back and forth. ASSY- 3. Remove the WASHER-WAVE DRUM from the SHAFT. 4. Remove the three screws holding the ASSY FLANGE SHAFT. Removal and Reassembly _ 31...
  • Page 34 Part Description Figure ASSY- 1. Remove the one screw DRUM holding the DRUM-LIFTER. 2. Release the HOOK. 3. Assemble the HOOK, DRUM- BACK, Holding it with screw. 32 _ Removal and Reassembly...

  • Page 35: Troubleshooting

    4. TroubleshooTing 4-1. error modes ► This is a washer integrated error mode. For detailed information, refer to the general repair scripts. drum Fully error Type Causes remarks error automatic error For usA mode mode - The part of the hose where the water level sensor is located is damaged (punctured). - The hose is clogged with foreign material. - The hose is folded.
  • Page 36 drum Fully error Type Causes remarks error automatic error For usA mode mode - The pump motor impeller is damaged internally. - The wrong voltage (220 V → 110 V) is supplied to the parts. - Part fault - This occurs due to freezing in the winter season drain error - The drain hose is clogged. (Injection error, foreign material) - Clogged with foreign material - The water pump terminal is not connected: rubber band, bills, cotton, hair pins, coins - This occurs when motor driving is unstable because the motor hall sensor does not work. - This occurs when the PBA IPM operation is motor error unstable or the control circuit has an error. - Check whether the wire connector is connected correctly or whether there is a contact error.
  • Page 37 drum Fully error Type Causes remarks error automatic error For usA mode mode - The Power button is pressed continually (for more than 12 seconds). - The switch is pressed unevenly because of a deformation of the control panel. - This error may occur when the screws that hold the sub PBA in place are tightened too much. - A button other than the Power button is switch error continually pressed (for more than 30 seconds). (main relay - Deformation of an internal plastic injection part error) - A screw for assembling the sub PBA is tightened too much. - The main relay of the PBA is short-circuited. When the - The main relay terminal is connected incorrectly. PBA motor relay does not (The terminal is bent and contact cannot be...
  • Page 38 drum Fully error Type Causes remarks error automatic error For usA mode mode - The washing heater is short-circuited or has a wire disconnected. For USA - The washing heater in the tub has an error. products, if (Contact error, temperature sensor fault) the heater has no error, - If the water level sensor operates without water this occurs because water is frozen or for any other reason because of and the temperature sensor engaged at the a PBA relay bottom to prevent overheating for the washing malfunction. heater detects a temperature of 100 to 150 ˚C, the washing machine turns the input power off. - This error occurs when the red temperature sensor at the center of the dry heater operates (at heater error (Heater a temperature higher than 145 ˚C) Relay) : Corrective action – Press the button at the...
  • Page 39 drum Fully error Type Causes remarks error automatic error For usA mode mode - The washing heater in the tub has an error. Heater sensor (Contact error, temperature sensor fault) fault - The connector is connected incorrectly or is : When the disconnected. connector is - If the water level sensor operates without water connected because the water is frozen or for any other incorrectly or reason and the temperature sensor engaged at has a wire the bottom to prevent overheating for the washing disconnected heater detects a temperature of 100 to 150 ˚C, or contact error the washing machine turns the input power off. Duct - The temperature sensor for the duct assy fan condensing Temperature housing is faulty.

  • Page 40: Corrective Actions For Each Error Code

    4-2. CorreCTive ACTions For eACh error Code 38 _ Troubleshooting...
  • Page 41 Troubleshooting _ 39...
  • Page 42 40 _ Troubleshooting...
  • Page 43 Troubleshooting _ 41...
  • Page 44 42 _ Troubleshooting...
  • Page 45 Troubleshooting _ 43...

  • Page 46: Pcb Diagram

    5. PCB Diagram 5-1. main PCB Location 项项 \Seine F3\GERBER\SEINE F3 POWER\ARNO-Sensorless-Power\ARNO-Sensorless-Power\PCB\Board2.pcb - Page 1 of 1 pages. Part no. Function Description Main Relay/ Power Supply Terminal Receive 220 ACV to operate the PBA Heater Realy For driving the heater power Water Level and Thermal Sensor Connection Terminal Detect the water supply / drainage and the heater operations Terminal for Each Driving Section...

  • Page 47: Circuit Diagrams Of Main Parts For Main Pcb

    5-2. CirCuit Diagrams oF main Parts For main PCB ► CN5 1. DOOR_UNLOCK 6. STEAM_VAL ► CN4 2. CIR_PUMP 7. PRE_VAL 1. MOTOR U 3. DRAIN_PUMP 8. COOL_VAL ► RELAY ► RELAY 2. MOTOR V 4. OPTION_PART 9. HOT_VAL 1. HEATER RELAY 1.

  • Page 48: Sub Pcb

    5-3. suB PCB Location Part no. Function Description BUZZER1 Buzzer Circuit Generates sound when the menu key and encoder-key are operated or when the menu is closed. Main and Sub PCB Connection Port Main and sub PBA communication. Program Writing Attach the connector for writing the program when an upgrade or change of the program is required.

  • Page 49: Detailed Descriptions Of Contact Terminals For Sub Pcb

    5-4. DetaiLeD DesCriPtions oF ContaCt terminaLs For suB PCB ► CN1 ► CN2 ► CN3 Programm writing Main and sub PCB communication Main and sub PCB communication PCB Diagram _ 47...

  • Page 50: Wiring Diagram

    6. Wiring Diagram 6-1. Wiring Diagram ■ reference information BLACK BLUE GREEN GRAY NATURAL ORANGE PINK SKYBLU SKYBLUE VIOLET WHITE YELLOW 48 _ Wiring Diagram...

  • Page 51: Schematic Diagram

    7. Schematic Diagram 7-1. main control ► This Document can not be used without Samsungs authorization. SAMSUNG PROPRIETARY THIS DOCUMENT CONTAINS CONFIDENTIAL, PROPRIETARY INFORMATION THAT IS SAMSUNG ELECTRONICS CO'S PROPERTY. DO NOT DISCLOSE TO OR DUPLICATE THIS DOCUMENT +15V_IS 1.5A +5V_IS 27ohm +15V_IS SF26 SF26 UF4007 UF4007 HALL SENSING...

  • Page 52: Sub Control

    HALL_A CGND CGND CGND HALL_B CGND 50 _ Schematic Diagram CHECKED BY DATE DESIGN PAGE MODEL NAME SAMSUNG NAME YYYY. MM. DD HH:MM AM SENSORLESS CONTROLLER ELECTRONICS DRAWN BY DATE APPROVED BY DATE SHEET SIZE PCB CODE LAST CHANGE DATE NAME YYYY.

  • Page 53: Reference

    8. RefeRence 8-1. SenIe PRoject name MoDel NaMe iN the Market BoM MoDel CoDe ► rPM Notation (Feature 3) ► Project Code ► Buyer Code ► Color Code ► Drum Machine Classification ► Capacity according to type: Sa Seine 0: 1000rpm 8: 800rpm WQ: DA WHITE 80: 8Kg 85: 8.5Kg WF: Washer Front Loading Sc Scout 2: 1200rpm S: Solide Door + STS WD: CRYSTAL WHITE (GLOSSY WHITE)
  • Page 54 Latin America gspn3.samsungcsportal.com China china.samsungportal.com This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2012 Samsung Electronics Co.,Ltd. All Any unauthorized use of Manual can be punished under applicable rights reserved. International and/or domestic law. 27 June 2012...
