- Page 1 HDMI to VGA+R/L Audio Converter HD VIDEO CONVERTER User Manual HDMI to VGA+R/L Audio Converter (Up to 4K) Bring High-Definition to your life!
- Page 2 HDMI to VGA+R/L Audio Converter Thank you for purchasing our product. To ensure safety and many years' trouble-free operation of the product, please read the manual carefully before using this product. 1.0 Introduction This kind of HDMI to VGA+R/L Audio Converter converts digital HDMI signal into analog VGA video and R/L audio signal.
- Page 3 HDMI to VGA+R/L Audio Converter Operating Frequency Vertical Frequency Range 30Hz Input video Amplifier 1.65Gbps/165MHz Bandwidth Mechanical Size(LxWxH) 73x60.5x22.5mm Weight(Net) 0.09Kg Warranty Limited Warranty 1 Year Parts and Labor Environmental Operating Temperature 0 to +70℃ Operating Humidity 10% to 85 % RH (no condensation) Storage Temperature -10 to +80℃...
-
Page 4: Installation And Precautions
HDMI to VGA+R/L Audio Converter 1. Connect the HDMI input from source device to this Converter.(Input cables are optional) 2. Connect the VGA and R/L audio output of this product to the display device. 3. Insert the DC side of 5V power supply into and then connect the AC side of the power supply into the wall outlet. - Page 5 HDMI to VGA+R/L Audio Converter professional maintenance staff.
