Please follow these steps to install your smoke alarm:
1. At the place where you are going to install your smoke alarm, draw a horizontal line 15cm
(6 inches) long.
2. Remove the mounting bracket from your unit by rotating it anticlockwise.
3. Place the bracket so that the two longest hole slots are aligned on the line. In each of
keyhole slots, draw a mark to locate a mounting plug and screw.
4. Remove the bracket.
5. Using a 3/16-inch(5mm) drill bit, drill two holes at the marks and insert plastic wall plugs.
Place the smoke alarm away from dust when drilling holes for mounting.
6. Using the two screws and plastic wall plugs (all supplied), attach the bracket to the wall.
7. Line up the slot of the bracket and the smoke alarm. Push the alarm onto the mounting
bracket on turn it clockwise to fix it into place. Make sure the smoke alarm is securely
attached to the mounting bracket.
Mounting
bracket
CAUTION: This smoke alarm comes with cover latches that will prevent the smoke alarm cover
from closing if battery is not installed. This tells you that the smoke alarm will not work until a
new battery is properly installed.
NOTE: When the alarm battery first makes contact with the alarm , the piezo sounder will beep.
This means the smoke alarm is working normally and also indicates that the battery is positioned
properly. Close cover, then press the test button, holding it down for about 3 seconds until the
piezo sounds. The piezo should sound a loud, pulsating alarm. This means the unit is working
properly.
Figure 9
The mounting bracket
5
Test button
& Power / Smoke Alarm
LED indicator
