The LED gives a visual indication of the wireless signal strength:
• Green indicates good signal strength and is a good location to install.
• Red indicates poor signal strength and the device should not be installed in that position.
• If no LED illuminates then the device is completely out of range.
Locations to install your smoke alarm
Smoke alarms should be installed in accordance with the NFPA Standard 72 (National Fire Protec-
tion Association). For complete coverage in residential units, smoke alarms should be installed in
all rooms, halls, storage areas, basements, and attics in each family living unit. Minimum cover-
age is one alarm on each floor and one in each sleeping area.
Figure 3
Locations for placing smoke alarms
for single residence with only one
sleeping area
Smoke alarms for minimum security
●
Smoke alarms for more security
○
Some useful tips:
• Install a smoke alarm in the hallway outside every separate bedroom area, as shown in
Figure 3. Two alarms are required in homes with two bedroom areas, as shown in Figure 4.
• Install a smoke alarm on every floor of a multi-floor home or apartment, as shown in Figure 5.
• Install a minimum of two alarms in any household.
• Install a smoke alarm inside every bedroom.
• Install smoke alarms at both ends of a bedroom hallway if the hallway is more than 40 feet
(12 metres) long.
Wireless signal strength test
Learn
button
LED
Figure 4
Locations for placing smoke alarms
for single-floor residence with more
than one sleeping area
Smoke alarms for minimum security
●
Smoke alarms for more security
○
Figure 2
Printed Circuit Board
2
Figure 5
Locations for placing smoke alarms
for multi-floor residence
Smoke alarms for minimum security
