PureTools PT-PMS-42S User Manual

4x2 hdmi 2.0 seamless matrix switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
PT-PMS-42S
User Manual
4x2 HDMI 2.0 Seamless Matrix Switcher
Model PT-PMS-42S
Designed in Germany
© 2019 PureLink GmbH All rights reserved.
V1.0
