ZyXEL Communications WAH1004 Quick Start Manual

Quick Start Guide

Hardware Installation

1
Slide open the cover (B) from back of the USB dongle.
1
1
Insert a SIM card and a micro SD card (optional). Slide close the
2
back cover (B).
1
Remove the cap (A) from the USB dongle and insert it into the USB
3
port of your computer.
1
Check the Windows taskbar or the Mac pop-up window to see if the
4
USB dongle is installed properly.

Driver/Utility Installation

For Windows:
The driver and utility will be automatically installed on your computer. If the
utility failed to install and/or the autorun screen does not display, go and find
a removable disk named ZyXEL 3G Modem on your computer instead.
Double-click StartModem.exe and follow the on-screen instructions to install
the ZyXEL 3G Modem utility.
1/2
WAH1004
USB 3G Modem
B
Insert the SIM card (and SD card) with the slanted side matching the
card holder and the metal contact area facing downwards into the
slot, and then push the SIM card (and SD card) as far as possible.
For Mac:
The driver and utility will be automatically installed on your computer. If the
utility failed to install and/or the autorun screen does not display, go and find
a removable disk named ZyXEL 3G Modem on your computer instead.
Double-click ZyXEL 3G Modem.pkg and follow the on-screen instructions to
install the ZyXEL 3G Modem utility.
Copyright © 2015 ZyXEL Communications Corp. All Rights Reserved

LED Information

Red blink: SIM error/No Service
Green: Connected to 2G/3G network
Green blink: Data transmitting
A
