Datasheet |
Multi-Rate Pluggable Transceivers
AT -SPLX40
Small Form Pluggable (SFP) Modules
AT -SPLX40
40km 1000LX SFP
Industry Standard
The AT-SP series offers the latest industry
standard in flexible, full-duplex Gigabit Ethernet
connectivity.These hot-swappable, fiber
interfaces simply plug into a SFP slot on Allied
Telesis SFP compatible products. Configurations
can be optimized to meet varied distance and
service requirements.
Options
The AT-SP series offers short-haul and long-haul
solutions. From the inexpensive AT-SPSX to the
far-reaching AT-SPZX80, you have the option to
extend your network to the distances that meet
your performance needs.The CWDM version
allows you to take advantage of the CWDM
technology in an existing network infrastructure,
maximizing fiber efficiency. Multi-rate versions
allow technologies other than just Gigabit
Ethernet to be transmitted over single-mode
fiber.
Product Compatibility
The AT-SP series SFPs are compatible with all
the Allied Telesis range of products that support
SFP uplink connections.
USA Headquarters
|
19800 North Creek Parkway
European Headquarters
|
Via Motta 24
Asia-Pacific Headquarters
|
11 Tai Seng Link
www.alliedtelesis.com
© 2007 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners.
Technical Specifications
Media Type
Wavelength
Maximum Data Rate
Distance
Digital Diagnostics
Transmit Power
(min) 0dBm
Transmit Power
(max) 5dBm
Receive Sensitivity
at 2.125Gbps (max) -21dBm
at 1.25Gbps (max) -22dBm
Power Budget
at 2.125Gbps (min) 21dBm
at 1.25Gbps (min) 22dBm
Fiber Connector:
Standard Data Rates Supported
Optical Gigabit Ethernet
1 x Fiber Channel
2 x Fiber Channel
Environmental Specifications
Operating Temp.
Operating Humidity
Storage Temperature
Storage Humidity
|
Suite 200
|
Bothell
|
|
6830 Chiasso
|
Switzerland
|
T: +41 91 69769.00
|
Singapore
|
534182
|
T: +65 6383 3832
SMF
1310nm
2.125Gbps
40km
Yes
LC
-10°C to 70°C
0% to 85% (non-condensing)
-40°C to 85°C
0% to 85% (non-condensing)
WA 98011
|
USA
|
T: +1 800 424 4284
|
F: +41 91 69769.11
|
F: +65 6383 3830
Key Features
•
Copper and fiber solutions
•
Connect up to 80km
•
Compact size
•
Flexible architecture
•
Plug & Play ease-of-use
•
Self-locking mechanism
•
'Colored' wavelength for CWDM use
•
Data: Support for fiber channel and 2x fiber
channel
•
Telecom: support for OC3/STM-1,
OC12/STM-4, and OC48/STM-16
•
Two year warranty
Ordering Information
AT-SPLX40
40km 1000LX SFP, 9 Micron SMF (1310nm)
|
F: +1 425 481 3895
617-000131 Rev C
