Allied Telesis AT-SPBD10-13 Specifications

Datasheet | Multi-Rate Pluggable Transceivers
AT -SPBD10
Small Form Pluggable (SFP) Modules
AT -SPBD10-13
10km, 1000LX SFP, Bi-Di
AT -SPBD10-14
10km, 1000LX SFP, Bi-Di
Industry Standard
The AT-SPBD10 offers the latest industry
standard in flexible, full-duplex Gigabit Ethernet
connectivity.These hot-swappable, fiber
interfaces simply plug into a SFP slot on Allied
Telesis SFP compatible products. Configurations
can be optimized to meet varied distance and
service requirements.
Allied Telesis
Options
The AT-SP series offers short-haul and long-haul
solutions. From the inexpensive AT-SPSX to the
far-reaching AT-SPZX80, you have the option to
extend your network to the distances that meet
your performance needs.The CWDM version
allows you to take advantage of the CWDM
technology in an existing network infrastructure,
maximizing fiber efficiency. Multi-rate versions
allow technologies other than just Gigabit
Ethernet to be transmitted over single-mode
fiber.
Product Compatibility
The AT-SP series SFPs are compatible with all
the Allied Telesis range of products that support
SFP uplink connections.
Key Features
• Copper and fiber solutions
• Connect up to 80km
• Compact size
• Flexible architecture
• Plug & Play ease-of-use
• Self-locking mechanism
• 'Colored' wavelength for CWDM use
• Data: Support for fiber channel and 2x fiber
channel
• Telecom: support for OC3/STM-1,
OC12/STM-4, & OC48/STM-16
• Two year warranty
Ordering Information
AT-SPBD10-13
10km, 1000LX SFP, 9 Micron
(Tx=1310nm, Rx=1490nm)
AT-SPBD10-14
10km, 1000LX SFP, 9 Micron
(Tx=1490nm, Rx=1310nm)
