- Page 1 S6 - VAN CONVERSION KIT MANUAL...
-
Page 2: Table Of Contents
Fresair Air Conditioning unit, that’s why we prepared this manual. Here you will find simple instructions for step-by-step installation, optimal performance, and operational procedures so you can get the most out of your Fresair. Table of Contents Main Components... -
Page 3: Main Components
➊ Remote Control IR receiver ➋ Low Water LED ➌ Water Pump on LED ➍ Fan on LED ➎ Fan On/Off ➏ Water Pump On/Off ➐ Interior Light On/Off ➑ Cycle through Fan Speeds (5 Fan speeds) Fresair, LLC. fresair.com... -
Page 4: Safety Information
Children must be supervised to ensure that they do not play with the product. • Do not undo the upper cover of the Fresair Air Conditioning Unit in case of a fire. Use approved extinguishing agents instead. Do not use water to extinguish fires. -
Page 5: Technical Data
Only install the Fresair Air Conditioning Unit using the installation instructions provided in the manual. The Fresair unit uses minimal 12V power to pull air from the outside of the vehicle, through an anti-bacterial and anti-fungal pine straw filter, delivering strong directional air through the four adjustable air vents. - Page 6 500 to 1500 ml/h depending on the external moisture and temperature Capacity 18L water tank Autonomy 15-22 hours Double fan with ohmic resistance Voltage Maximum Nominal Current 12V/10A Fan Speed 4000 rpm Weight Maximum Air Flow 400 m³/h Insulation Class 1Ω Fresair, LLC. fresair.com...
-
Page 7: Technical Assistance
Technical Assistance Fresair is committed to providing guidance to ensure optimal performance, understanding routine maintenance and preventative care. Should you need any assistance or guidance on performance, preventative care, maintenance or general questions please contact an authorized dealer or reach out to us directly at support@fresair.com. -
Page 8: Operation Information
Fresair Air Conditioning unit. • Do not insert foreign objects into the system. Observe the following instructions to ensure your Fresair Air Conditioning Unit is used properly and efficiently. It is recommended that you •... -
Page 9: Warranty Information
In no case will Fresair exchange the product for a replacement solely due to a defective component. A. Damages caused by accidents;... -
Page 10: Parts: Maintenance
WATER PUMPS • INJECTION: The injection pump is located on the outside of the water reservoir and sends water to the Fresair unit. • RETURN: The return pump is located in the tray and returns excess water to the reservoir. - Page 11 NOTICE! Periodical maintenance is essential for optimal performance and prolonging the life of your Fresair Air Conditioning unit. We recommend preventative maintenance and replacing of wearable parts annually or as outlined in the manual, coinciding with your yearly vehicle maintenance.
-
Page 12: Parts: Installation
Parts: Installation UNIT (1) Fresair Unit (1) Fresair Finishing Frame LOOSE (1) Cardboard Mounting (1) 3/4” (Thick) x 76” Reel Self- Template Sticking Sealing Foam (inner seal around airbox) (1) 3/8” (Thin) x 110” Reel Self Sticking Sealing Foam (Outer Edge of Unit) BAG #1 (10) 8”... - Page 13 *NOTE: Use only 4 bolts to secure (Bold head ➔ (8) M8 Self Locking Nylon Rubber ‘O’ Ring ➔ Unit/Roof ➔ Washer ➔ Nut. Nuts (4 - Unit, 4 - Reservoir) Choose bolt length best suited to specific installation. Fresair, LLC. fresair.com...
-
Page 14: How To Install
Prep Tip: It is very important that the roof surface is clean to ensure a weather-tight seal between the base of the Fresair unit and your roof. Take time to determine where you wish to install your Fresair. Ensure that the unit is placed between roof support bars so you don’t compromise roof integrity. - Page 15 Step 3 - Testing the Fit What you’ll need: Fresair Unit • Test the fit of the Fresair Unit by lowering it in the area you’ve just cut out and make any necessary adjustments accordingly. Be careful not to crimp or damage the water hoses Step 4 - Drop in the Bolts What you’ll need: Fresair Unit, Screwdriver, 8MM/5/16”...
- Page 16 Figure 2 Step 5 - Adhering the Sealing Foam Tape What you’ll need: Fresair Unit, Sealing Foam Tape • With the unit still in place and secure, use a permanent marker to draw an outline around the outside base of the unit on the roof.
- Page 17 Step 6 - Mounting the Fresair Unit What you’ll need: Fresair Unit, 4 Bolts, 4 Washers, 4 Nuts, 4 Waterproof Bolt Caps, 6 Cover Screws, 2 Finishing Frame Screws, *Screwdriver, *Crescent Wrench(es), *Self- leveling lap sealant/Silicone •...
- Page 18 • Connect the negative wire (black) to the negative terminal of your fuse block. • Ensure both wire connections are tightened properly and completely secured to the fuse block. • Next, test the power (using the Fresair power button on the unit) to ensure your unit turns on. Electrical Wiring...
- Page 19 • Connect the electrical connectors to the float sensor and injection pump. • Once you’re ready, fill your reservoir with water and seal with the provided cap. • Finally, power on your Fresair and ensure there are no leaks. • Additionally, test all functions to ensure your Fresair is working properly.
- Page 20 How to Install Vertical Reservoir Figure 5 Water return line Negative connection Fuse Positive connection Float Sensor Water pump & connector Water injection line Fresair, LLC. fresair.com...
- Page 21 Horizontal Reservoir Figure 6 Water injection line Water pump & connector Water return line Float Sensor Negative connection Fuse Positive connection Fresair, LLC. fresair.com...
-
Page 22: Cleaning & Care
Cleaning & Care Please observe the following tops for the cleaning and care of your Fresair Air Conditioning Unit. • Clean the external cover of the unit removing dirt and debris on and around the unit as often as you wash your vehicle. - Page 23 YOUR LOCAL YOUR LOCAL DEALER SUPPORT fresair.com/dealer fresair.com/contact...
