ULTRASONIC WATER
METER QALCOSONIC W1
TECHNICAL DESCRIPTION,
INSTALLATION MANUAL
AND USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QALCOSONIC W1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Axioma QALCOSONIC W1

  • Page 1 ULTRASONIC WATER METER QALCOSONIC W1 TECHNICAL DESCRIPTION, INSTALLATION MANUAL AND USER GUIDE...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATIO 1 APPLICATION FIELD 2 TECHNICAL DATA 2.1 DISPLAY (LCD) 2.2 DATA RECORDING AND STORAGE 2.3 ALARMS 2.4 EXTERNAL COMMUNICATION MODULES AND INTERFACES 2.5 PULSE OUTPUTS IN TEST MODE 2.6 POWER SUPPLY 2.7 MECHANICAL DATA 2.8 OPERATION CONDITIONS 3 OPERATING PRINCIPLE 4 MARKING AND SEALING 4.1 MARKING...
  • Page 3: Safety Informatio

    EU DECLARATION OF CONFORMITY AXIOMA Metering UAB, Veterinarų g. 52, Biruliškių k., Kauno raj., Lithuania, hereby declares that the water meter QALCOSONIC W1 conforms to the essential requirements of the following Directives: 2014/32/EU Directive 2014/32/EU of the 26 February 2014 on the harmonisation of...
  • Page 4 ORDERING CODE COMBINATION OF THE METER *: Meter QALCOSONIC W1 Type THE RATIO R (Q CODE PERMANENT FLOW OVERALL CODE RATE Q LENGTH L, MM CONNECTIONS G ¾ G ¾ G ¾ G ¾ G ¾ G ¾ G ¾...
  • Page 5: Technical Data

    2 TECHNICAL DATA Ratio of the permanent flow rate to the lower limit of the flow-rate (selectable by the user): = 250 , Q = 315, Q = 400, Q = 800 The technical data of the meter are provided in Table 1.1. 1.1.
  • Page 6: Display (Lcd)

    WORKING TEMPERATURE RANGE: Meter temperature class T30 (0,1°C ... 30°C) Meter temperature class T50 (0,1°C ... 50°C) Meter temperature class T30/90 (30°C ... 90°C) Meter temperature class T90 (0,1°C ... 90°C) • Maximum admissible working pressure (pressure class) 16 bar (MAP16) •...
  • Page 7: Alarms

    16 years. 2.3 ALARMS Qalcosonic W1 meter has integrated system that informs about certain alarms. Several of them are critical and being transmitted immediately. Other alarms or events are logged in status byte and transmitted within data telegrams.
  • Page 8: Pulse Outputs In Test Mode

    Accurate battery lifetime depends also on data transmission frequency. 2.7 MECHANICAL DATA Dimensions of Qalcosonic W1 water meter are not greater than 75 mm x 77 mm x 190 mm (DN20, L190). WEIGHT OF DIFFERENT SIZES OF QALCOSONIC W1 WATER METERS ARE SHOWN IN THE TABLE BELOW:...
  • Page 9: Marking And Sealing

    4 MARKING AND SEALING 4.1 MARKING There is following information on the front facture and serial number, permanent flow witch the meter shall be replaced, software panel of the calculator of the meter: EC- rate Q3 and ratio R (Q3/Q1), temperature version number, IP code, communication type examination certificate number, man- class, maximum admissible working pres-...
  • Page 10: Mounting

    In order to avoid stresses in the pipelines, ment should not be higher than 70°C. downstream the meter is not necessary the distance between the meter con- (Qalcosonic W1 flow profile sensitivity nection points in the meter installation No special requirements are established class is U0 D0).
  • Page 11: Menu Structure

    6.2 MENU STRUCTURE Menu structure in normal mode is presented in Fig. 6.1. Meter menu stages switches automatically. Individual stages, except total volume and info status code, could be disabled during instal- lation. Error code is displayed only when an error occurs during meter operation. In normal mode this stage is skipped. Fig.
  • Page 12: Viewing The Readings In Normal Mode (User Menu)

    6.3 VIEWING THE READINGS IN NORMAL MODE (USER MENU) REMARK: here the full list of shown parameters is represented. For the specific meter it can be reduced. PARAMETER VALUE (EXAMPLE) REMARKS Total volume Flow rate 1 331 Forward flow volume Informational volume of total reverse flow Water temperature value...
  • Page 13: Viewing The Readings In Verification (Test) Mode

    The indication of irrelevant parameters can be turned off. Also, parameters that are not relevant to the set meter configuration will not be indicated. The indication of parameters can be turned on or off by means of the configuration software „W1 TOOL“ through the optical interface when installing the meter (if the meter is in the transportation mode).
  • Page 14: Verification (Test) Mode Control

    Active info codes are added, if there is detected more than one error. Then the summary indicated info code will be as follows: 3 - corresponds errors 2 + 1 A - corresponds errors 8 + 2 D - corresponds errors 8 + 4 + 1 5 - corresponds errors 4 + 1 B - corresponds errors 8 + 2 + 1 E - corresponds errors 8 + 4 + 2...
  • Page 15: Annex A

    ANNEX A Sizes and dimensions of water meter QALCOSONIC W1 A.1 DN 20: MODEL L, MM DN20 L105 DN20 L110 DN20 L130 DN20 L165 DN20 L190 axiomametering.com...
  • Page 16 ANNEX A Sizes and dimensions of water meter QALCOSONIC W1 A.2 DN 15: MODEL L, MM DN15 L80 DN15 L105 DN15 L110 DN15 L165 DN15 L170 axiomametering.com...
  • Page 17: Annex B

    ANNEX B Example of sealing water meter after installation. axiomametering.com...
  • Page 18: Warranty

    Warranty period is 6 years from manufacturing date, with additional possibility to extend it for additional charge. MANUFACTURER’S ADDRESS: UAB “Axioma Metering”, Veterinarų g. 52, Biruliškių k., Kauno raj., Lithuania tel. +370 37 360234, fax. +370 37 360358. axiomametering.com...
  • Page 19 Where innovation UAB „Axioma Metering“ becomes metering@axioma.eu axiomametering.com affordable QALCOSONIC W1...
