UE Systems GREASE CADDY ULTRAPROBE 201 Visual Instructions page 2

Identification of Parts on ULTRAPROBE
201 "GREASE CADDY"
Ultraprobe 201
"Grease Caddy"
Magnetic Transducer
Clamp to Grease Gun
Hard Hat Head Phones
10 LEDs to note change. ON/OFF Buttons w/
5min auto off. 8 Position Sensitivity Selector
with '0' being highest sensitivity.
ON Button
Low Battery
Indicator
"0" is Highest
Sensitivity
Low Battery
Indicator
201
Adjustable
Ball Mount
OFF Button
10 LED Lights
Head Phone
Jack (3.5 mm)
"70" is Lowest
Sensitivity
IDENTIFICATION
The "Grease Caddy" can be attached to a Grease
Gun or WORN IN A HOLSTER w/Belt Clip.
Possible Location of Magnet on Bearing Housing,
side of Housing. Never on Fan Shrouds or Covers.
Use Grease fitting if possible.
To Headphones
Magnetic
Transducer
UP 201 "Grease Caddy"
Holster for UP 201
Grease Fitting
RMT on Bearing Housing
