- Page 1 USER MANUAL Juplink EC4-1200 Wireless Range Extender...
-
Page 2: Table Of Contents
Content Chapter 1 Product Overview ......................3 1.1. Package Contents ....................... 3 1.2. Getting to Know Your Wireless Range Extender ..............3 1.3. Placing Your Wireless Range Extender ................5 Chapter 2 Internet Connection Setup ....................7 2.1. Hardware Installation ......................7 2.2 Connecting Your Range Extender .................. -
Page 3: Chapter 1 Product Overview
Chapter 1 Product Overview 1.1. Package Contents Thanks for purchasing the Juplink EC4-1200 Wireless Range Extender. You will find the following items in the box: • 1 x Wireless Range Extender • 1 x Quick Start Guide Note: If either of the above is incorrect, missing, or damaged, please contact us at support@Juplink.com for replacement. - Page 4 Status Description Powered off. POWER Powered on. No Wi-Fi connection or powered off. Wi-Fi connected, but no data being 2.4G / 5G transmitted. Flashing Data being transmitted. WPS disabled or device powered off. WPS enabled and connected.
-
Page 5: Placing Your Wireless Range Extender
WPS enabled and connection being Flashing established. One LED on Weak receiving, strength below 25%. Wi-Fi Signal Strength Two LEDs on Good receiving, strength of 50~75%. (3 strips without Excellent receiving, strength of silkprinting) Three LEDs on 75~100%. Port & Button Port/button Description LAN/WAN... -
Page 7: Chapter 2 Internet Connection Setup
Chapter 2 Internet Connection Setup 2.1. Hardware Installation ① Place the wireless range extender close to a wireless router or access point and then plug it into a power outlet nearby. Please ensure the right side switch is ON ② Connect your wireless clients (such as a notebook, tablet, smart phone, etc.) to the range extender wirelessly. -
Page 8: Logging In To Your Range Extender
Range Extender Follow the steps below to log in to your ① Open a Web browser and enter 192.168.0.2 or router.Juplink.com* in the address (Only for Firmware v1.0.2) bar. ② Enter Username admin and Password admin, then click Log in (You can modify... -
Page 9: Chapter 3 Internet Connection
Chapter 3 Internet Connection 3.1 Manually Setting Up Internet Connection - Repeater/Client (default) Connect your mobile device to the Range Extender with an Ethernet cable or via wireless connection and log in to the Range Extender. ① Select Repeater (default). ②... -
Page 10: Manually Setting Up Internet Connection - Access Point (Ap)
Note: -It may take a few second to scan the network, If you can't find the signal you want to expand. Click Site Survey button search the signal again. ③ Enter the password of the Wi-Fi network you want to extend. ④... -
Page 11: Manually Setting Up Internet Connection-Router
① Select Access Point (AP) ② Select Auto. Configure LAN IP address. Set the Network Name (SSID), Pre-Shared Key (password), and click the Save&Apply button to complete the setup. Your settings are now applied and the Range Extender is ready to serve as an access point. - Page 12 modem. - You need sSelect Fixed IP, Auto Config. (DHCP) or PPPoE Dial-Up according to your actual condition or the mode required by your ISP. Below is the detailed method of setting in Router mde. 3.2.1. Router-Auto Config. (DHCP) ① Select Auto Config. (DHCP). This is the default setting. ②...
- Page 13 ② Set the Network Name (SSID) and Pre-Shared Key (password). ③ Enter the information of IP address, Subnet Mask, Default Gateway, DNS (if necessary). ④ Click Auto Fill next to the MAC Address Clone field, and click Save&Apply. Your settings are now applied and the Range Extender is ready to serve as a router. 3.2.3.
-
Page 14: Chapter 4 Maintaining The Range Extender
Chapter 4 Maintaining the Range Extender 4.1 Changing the User Name and Password of the Range Extender You can change the user name and password to log in to the Range Extender. ① After logging in to the Range Extender, click Advanced at top of the Web page. ②... -
Page 15: Time Zone Setting
factory default settings. 4.3 Time Zone Setting You can maintain the system time by synchronizing with a public time server on the Internet. Copy Computer Time: It is applicable for Windows devices only, and is not recommended. Enable NTP client Update: Select the check box, and select a stable NTP server from the drop-down list or manually enter the address of an NTP server. -
Page 16: Diagnostics
4.5 Diagnostics This page is used to run system commands. 4.5.1 Diagnostic Command - PING ① After logging in to the Range Extender, click Advanced at top of the Web page. ② Choose Management > Diagnostics. ③ Select PING from the Diagnostic Command drop-down list. ④... -
Page 17: Change Login Address
4.6 Change Login Address To change the default login address, do as follows: ① After logging in to the Range Extender, click Advanced at top of the Web page. ② Choose Network > LAN Settings. ③ Enter an IP Address in the IP Address field. After clicking Save&Apply, you can log in to the Range Extender using this IP address. -
Page 18: Chapter 5 Advanced Internet Configuration Of The Range Extender
Chapter 5 Advanced Internet Configuration of the Range Extender 5.1 Static DHCP Setup (IP Address reservation) This page allows you to reserve IP addresses and assign the same IP address to a network device with a specified MAC address each time it requests an IP address. This is similar to having a static IP address except that the device needs to request an IP address from the DHCP server every time. -
Page 19: Wireless Basic Settings
5.2 Wireless Basic Settings This page allows you to configure wireless clients to be connected to the Range Extender. 5.2.1 Selecting Country ① After logging in to the Range Extender, click Advanced at top of the Web page. ② Choose Wireless > WLAN1(5GHz) > Basic Settings or Wireless >... - Page 20 5.2.3 Switching A Channel ① After logging in to the Range Extender, click Advanced at top of the Web page. ② Choose Wireless > WLAN1(5GHz) > Basic Settings or Wireless > WLAN2(2.4GHz) > Basic Settings, depending on which band you want to configure. ③...
- Page 21 5.2.5 Wireless Security Setup This page allows you to set up wireless security. Using WEP or WPA Encryption Key helps prevent unauthorized access to your wireless network. ① After logging in to the Range Extender, click Advanced at top of the Web page. ②...
- Page 22 5.2.7 Wi-Fi Protected Setup-WPS setting This page allows you to change the settings for WPS (Wi-Fi Protected Setup). Using this feature allows a wireless client to automatically synchronize its settings and connect to the Range Extender in a secured manner. ①...
- Page 24 Q1: Why is my Power light off and the extender not working? A1: Please ensure the right side switch is ON Q2: How to reset the repeater? A2: When the POWER LED of the repeater is solid on, press the RESET button on the repeater and hold for 8 seconds and then release.
- Page 25 • Open a browser, enter the IP address in the address bar, and then you can access the Web page of the repeater. Method 3: (recommended) • Download device firmware file v1.0.2 from juplink.com and conduct firmware upgrade. • After reset, try logging in to domain name: router.juplink.com Q5: Why can l find someone else's Wi-Fi network, but not mine? •...
- Page 26 solid green. Q8: Why is there no Internet access after extension? A8: • Check if the extension is successful (by observing the indicator and Web page). • Disconnect the device that is without Internet access, and connect again to see if it becomes available.
- Page 27 repeater to the router again. ③ Reset the repeater. Q13: Why does the wireless network show strong signal strength but low speed after extension? A13: Check the signal strength indicator on the physical housing of the repeater. ① One LED on: weak receiving signal, strength below 25%. (In this case, it is recommended to put the repeater closer to the router, and keep their antennas in parallel.) ②...
- Page 28 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
