Kuranda Cat Tower Assembly Instructions

Assembly Instructions For Kuranda 2 Tier Cat Tower
Tools Needed – Phillips Head Screwdriver, 7/16
Wrench or Adjustable Wrench
Flat surface to work on (table preferred)

Parts List-

2 Fabric Mats
8 PVC slotted pipe (4 long / 4 short)
8 PVC 11" legs – 4 leg caps
4 top corners – 12 bottom corners
8 machine screws, 8 pan head screws (2 ¾"),
16 lock nuts
1) Lay fabric flat with underside facing up and
insert cording into sleeves.
NOTE: Heat welded fabrics have the cording already
encased in outer edge of fabric.
2) Insert fabric into the channel on each length
of pipe.
3) On bottom bed fabric, Secure two bottom
corners (as oriented in the picture below) with
pan head screws and lock nuts. You can insert
the bunk post into the corner as well.
4) Tighten bolts, be careful not to overtighten.
3
1
5) Check top corners to be sure they are
square. Set top fabric with pipe sleeves on
top of upper corners. Screw top corners
into place using machine screws and
locknuts.
6) Place rubber caps on 11" legs and
insert legs into corners.
2
NOTE: TIGHTEN PROPERLY – correct
tightening will leave end of bolt flush with
4
the nuts' white nylon locking material.
INSUFFICIENT OR OVER TIGHTENING
OF THE CORNERS MAY RESULT IN
CRACKING.
5
