Kuranda Standard Almond Assembly Instructions

Assembly Instructions For Kuranda Dog Beds
Parts List
(1) Fabric Mat
(4) Pieces black plastic tube (small diameter)
(1) Hardware Kit - (8) Screws, (8) Locknuts
(4) Top Corner Brackets
(4) Bottom Corner Brackets
(4) Legs and (4) Leg caps
(2) Slotted Rails – Short
(2) Slotted Rails - Long (Note: X- Large and
XX-Large beds include metal reinforcing
tubes inside long rails for added strength.)
Tools Needed
Head Screwdriver
11 mm or 7/16 Wrench or Adjustable Wrench
Flat surface to work on (table preferred)
1. Lay fabric flat with underside facing up
(hem showing) and insert small black tube into
sleeves. (This step is not required for Heavy
Duty Vinyl fabric as white cording is inserted in
hem during production of the fabric. )
2 Insert fabric sleeves into the slot on each
length of bed rail.
3. With the underside of the fabric facing up,
position a top corner bracket beneath bed rails
and insert screw through holes in each rail.
(Note: Reinforcing tubes may shift inside frame
during shipping and block a bolt hole. Push
tube with screwdriver to recenter the pipe
between holes.)
4. Place a bottom fitting in position, secure
with a lock nut and hand tighten. Insert and
secure second screw. Repeat for other three
corners.
5. Place rubber caps in legs and insert legs
into corners.
