Installation Instructions
MA114 Series
MIMO 5G/4G Antenna
Introduction
Following these guidelines will help ensure that your Taoglas
MA114 antenna is installed correctly. The MA114 is be
mounted via permanent through-hole mounting, as outlined
below.
Installation Requirements
Antenna Components:
Hex Steel Nut & Washer (x1), Antenna Housing (x1), Coaxial Cable(x2), Pre-adhered Adhesive Pad(x1)
•
Additional Requirements:
Drill with 16mm(5/8") drill bit/hole saw
19mm [3/4in] hex wrench (optional)
Notices
Caution
To comply with FCC RF Exposure requirements in section 1.1310 of the FCC Rules, antennas used with this device must be installed
to provide a separation distance of at least 20 cm from all persons to satisfy RF exposure compliance.
Warning
Do not Operate the transmitter when someone is within 20 cm of the antenna.
Do not operate the equipment in an explosive atmosphere.
European Waste Electronic Equipment Directive 2002/96/EC
Please ensure that your old Waste Electricals and Electronics are recycled do not throw them away into standard waste.
Waiver: This document represents information compiled by Taoglas to the best of our current knowledge. This is not intended to be used as a
representation or warranty of fitness of the products described for any particular purpose. This document details guidelines for general information
purposes only. When planning installations, always seek specialist advice and ensure that the products are always installed by a properly qualified installer
in accordance with applicable regional laws and regulations.
All copyrights, trademarks and any other intellectual property rights related are owned by Taoglas Group Holdings Limited.
IG-21-8-017-A
www.taoglas.com
Advertisement
Table of Contents
Related Manuals for Taoglas MA114 Series
Summary of Contents for Taoglas MA114 Series
- Page 1 Please ensure that your old Waste Electricals and Electronics are recycled do not throw them away into standard waste. Waiver: This document represents information compiled by Taoglas to the best of our current knowledge. This is not intended to be used as a representation or warranty of fitness of the products described for any particular purpose.
- Page 2 Note: Avoid sharp bends when routing coaxial cable. Note: Once exposed, avoid touching the adhesive. Insert the coaxial cables through the washer and steel Completed Installation. nut and slide them upwards. Tighten to secure the antenna in place. Ensure the nut is fully tightened. www.taoglas.com IG-21-8-017-A...
