Advanced Configurations

DCP Configurations: Dipswitch (SW1)
SW1 Function
1
Signal tester
2
Not used
3
Reserved
4
CAN Ω
DAU Configurations: Dipswitch (17)
SW1 Function
1
Shaft (car)
number
2
Not used
3
CAN Ω
Additional Information for Programming the DCP
ADDITIONAL INFORMATION FOR PROGRAMMING THE DCP
+
All DCP parameters can be remotely configured via SMS sent to the SIM card's number.
+
Each SMS message should begin with 'Pin1234' which is the access code to read or make any changes to the
configuration of the DCP.
+ You can modify or check several parameters in each SMS by separating them with commas ","
To send parameter information:
Text
Pin1234, Pzzz xxx (send)
To read parameter information:
Text
PinXXXX, Pzzz? (send)
Avire internal use only
Activates the CANBus End of Line (EOL) for the CAN connector.
Default ON – DCP is typically an End of Line device.
Default OFF, OFF – DAU always in shaft 1 as part of the DCP.
(Function not necessary for DCP WAVE, leave as default)
Activates the CANBus End of Line (EOL) for the CAN connector.
Default ON – DAU is always the End of Line device.
Description
• Pin1234 is default PIN code for DCP
• Pzzz is the programming command
• xxx is the parameter
Description
• Pin1234 is default PIN code for DCP
• Pzzz is the programming command
• "?" is to request a parameter read
Description
Inbuilt signal tester
Default OFF
Not used
Default OFF
Description
Not used
