FWB MultiBall Pro Setup Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

MultiBall Pro - Setup Guide 3.2
Fun With Balls GmbH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MultiBall Pro and is the answer not in the manual?

Questions and answers

Related Manuals for FWB MultiBall Pro

Summary of Contents for FWB MultiBall Pro

  • Page 1 MultiBall Pro - Setup Guide 3.2 Fun With Balls GmbH...
  • Page 2 Technical Specifications MultiBall Pro What's In The Box Connectivity Console Power: 110V / 220V / 230V Sensor Frame Internet: Ethernet / USB (Mobile Hotspot) AC Power Cord Video: HDMI (use quality cables) Installation Guide Audio Dimensions (WxHxD) Internal Sound System...
  • Page 3 Technical Specifications MultiBall Club The System needs a Projector, that is mounted as close and high as possible to avoid shadows. • Use a high quality HDMI cable. Recommended Projectors: • Panasonic PT-VMZ40 • Panasonic PT-VMZ60 • Panasonic PT-VZ470 Required Resolution: •...
  • Page 4 Dimensions in mm 1599 mm 138 mm 4890 mm...
  • Page 5 Hardware Console Cover (x8) Holder (x9) Sensor (x12) Sensor Bolt M4 (x40) Cover Bolt M6 (x32)
  • Page 6 Cable Management There are 7 cable outlets to run the HDMI, LAN and power cable. 1599 mm 138 mm 4890 mm...

  • Page 7: Recommended Equipment

    Recommended Equipment There are 52 holes with a diameter of 8mm. Screws and Dowels Ladder Laser Level Allen Key Set Drill for Wall Mounting...
  • Page 8 Step 1 Open Console Remove the 6 screws and lift up the cover.
  • Page 9 Step 2 Mount Holders and Console 1. Mount the Bottom Holders Left, Middle and Right touching each other. (Distance to floor 20mm) 2. Mount Left Side and Right Side. 3. Verify Left and Right are fully leveled and parallel. 4. Mount Top Left and Top Right. 5.
  • Page 10 Step 2 Mount Console Secure the Console with 7 bolts.

  • Page 11: Step 3 Mount The Sensors

    Step 3 Mount the Sensors Mount all Sensors with the red surface facing inwards. The sticker must face you. Use Sensor Bolt M4. Sensor Bolt M4 Do not over-tighten the bolts!

  • Page 12: Step 4 Connect Sensors

    Step 4 Connect Sensors 1. Connect the Sensor Top Left with Top Left Middle and the Sensor Bottom Left with Bottom Left Middle. 2. Connect the Sensor Top Right with Top Right Middle and the Sensor Bottom Right with Bottom Right Middle. Handle the Connectors with care and tighten them.

  • Page 13: Step 5 Cable Connections

    Step 5 Cable connections Connect the Sensor Cables with the Controllers. Sender Empfänger...
  • Page 14 Step 5 Cable connections 1. Connect the Console to power outlet and to Internet. 2. Connect the projector via HDMI. HDMI Power Volume Controle...
  • Page 15 Step 6 Setup Controller (1, 2, 3, and 4) 1. Power off Controller 1, 2, 3 and 4 by the switches. 2. Switch up the DIP 3 on Controller 1. 3. Power on the Controller 1. 4. Switch down the DIP 3 on the Controller 1 and wait until the „OUT 4 / IN 2“...
  • Page 16 Step 7 Mount Covers 1. Mount the Covers with the sensor holes facing inwards. 2. Use Cover Bolt M6. Cover Bolt M6 Carefully slide in the covers and avoid pinching or bending the light bar cables! Use provided bolts. If using an electric impact drill, make sure not to damage Once covers are on repeat Step 6 “Calibrate LVXs”...
  • Page 17 Step 8 Adjust Projector 1. Disconnect the Console from the power outlet. 2. Switch on the projector. 3. Connect the Console to the power outlet. To get a picture, always make sure you power on the projector first and Using ‘Shift’ and ‘Corner Correction’ in your projector, align then the MultiBall console.
  • Page 18 Step 9 Mount MultiBall Console Cover 1. Put back the Cover. 2. Use Cover Bolt M6. Cover Bolt M6 Use this step to adjust the volume of the amplifier. The volume can also be adjusted in the menu so try to find the best level suitable for you.

  • Page 19: Maintenance

    Maintenance 1. Do not block the Sensors. 2. Do not step on the Sensor Frame. Vacuum sensors once a week. (with covers on) In case of any problems of system not working, always first Take care of the system to avoid any kind of physical check the Sensors if they are clean and without any damage.

  • Page 20: Home Screen

    Home Screen 1. Choose between Games and Trainings. 2. Start by touching an icon. 3. Remote control by Smart Phone. Scan QR- Code to connect with the MultiBall Smart Phone App.

  • Page 21: In-Game Menu

    In-Game Menu 1. You can open the In-Game menu by touching the surface while playing a game. 2. Here you can go back to the home screen, resume or restart the game and adjust the volume.
  • Page 22 MultiBall Sportification App App download: FUN WITH BALLS GmbH Gyßlingstraße 72 Apple 80805 München Android Germany +49 89 323 099 61 www.funwithballs.com www.multi-ball.com...
