Installation/Owner's Manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Lyric Series
Models:
WARNING:
DO NOT attempt to access or change the
setting of the fuel selection means.
Access to and adjustment of the fuel se-
lection means must only be performed
by a qualified service person when con-
necting this appliance to a specified fuel
supply at the time of installation.
Change of this selector setting to other
than the fuel type specified at the time of
installation could damage this appliance
and render it inoperable.
The installer shall replace the access
cover before completing the installation
and operating this appliance.
Appliance Setup, Care and Operation
Monessen • Lyric Owner's/Installation Manual • 4616-900 Rev. H • 04/21
WARNING:
FIRE OR EXPLOSION HAZARD
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• WHAT TO DO IF YOU SMELL GAS
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
• This is an unvented gas-fired heater. It uses
air (oxygen) from the room in which it is in-
stalled. Provisions for adequate combustion
and ventilation air must be provided. Refer
to Section 2, page 8.
• This appliance may be installed in an after-
market, permanently located, manufactured
(mobile) home, where not prohibited by local
codes.
•
This appliance only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases.
1
