FCI HT-0066 Operation And Service Manual

Mini pvc terminal 22-26 awg
Hide thumbs

Advertisement

Quick Links

Download this manual
FCI
Issued: Date (11/16/95)
Rev. 10/02/01 ECR V10357
K\DCU\Manuals
Hand Tool 0066
Mini PVC Terminal 22 –26 AWG
Operation and Service Manual
FCI Tool P/N HT-0066
FCI MANUAL P/N 166813
PDM: Rev:B
Manual Part No. 166813-001
Page 1 of 6
Revision B
Released
STATUS:
Printed: May 10, 2010
.

Advertisement

loading

Related Manuals for FCI HT-0066

Summary of Contents for FCI HT-0066

  • Page 1 Hand Tool 0066 Mini PVC Terminal 22 –26 AWG Operation and Service Manual FCI Tool P/N HT-0066 FCI MANUAL P/N 166813 Manual Part No. 166813-001 Issued: Date (11/16/95) Page 1 of 6 Rev. 10/02/01 ECR V10357 Revision B K\DCU\Manuals PDM: Rev:B...

  • Page 2: Table Of Contents

    Parts List..............................5 SERVICE...............................6 Service.................................6 Parts Replacement............................6 REFERENCE DOCUMENTS FORM # E-3246- - Hand Tool Warranty FORM # E-3247- - FCI Electronics Address List Manual Part No. 166813-001 Issued: Date (11/16/95) Page 2 of 6 Rev. 10/02/01 ECR V10357 Revision B...

  • Page 3: Operation

    Operation Crimping Instructions To Load Terminal: 1. Press terminal holder as shown in Figure 1. 2. Insert terminal with “U” shaped barrels up, onto terminal holder pin until terminal is against pin shoulder. When using wire with regular insulation, place terminal in side marked “A”. When using wire with coax insulation, place terminal in side marked “B”.
  • Page 4 Figure 2 Figure 3 Manual Part No. 166813-001 Issued: Date (11/16/95) Page 4 of 6 Rev. 10/02/01 ECR V10357 Revision B K\DCU\Manuals PDM: Rev:B Released STATUS: Printed: May 10, 2010...

  • Page 5: Parts List

    Parts List HT-0066 – Mini PVC Terminal Wire Size 22 26 Detail No. Description Part No. Crimper Holder 155089-001 Insulation Crimper B117021-1 Wire Barrel Crimper 102605-1 Anvil Holder 102466-1 Insulation Anvil A117022-1 Wire Anvil (2) 105313-1 Terminal Holder 102467-2 Adjustable Tool Holder...

  • Page 6: Service

    Service Service • WHAT TO DO IF YOU NEED SERVICE: In the event service or technical help is needed FCI Electronics provides a toll free number. For service or technical help call 1-800-843-6911. Parts Replacement • PARTS REPLACEMENT: When calling for spare parts, have part number(s) ready for the customer service person. Number(s) can be obtained from the reference drawings located in the back of this manual.
