Fly Safe
Fly in Open Areas Strong GPS Signal
Avoid flying over or near obstacles, crowds, high voltage power lines, trees,airport or bodies of water.
DO NOT fly near strong electromagnetic sources such as power lines and base stations as it may affect
the onboard compass.
DO NOT use the drone in adverse weather conditions such as rain, snow, fog and wind speeds
exceeding 10 m/s or 22 mph.
Stay away from the rotating propellers
and motors.
It's important to understand basic flight guidelines, for the safety of both you and those around
you. Don't forget to read the Safety Guidelines before flight.
Maintain Line Fly Below
of Sight 400 feet (120 m)
≥ 10m/s
No Fly Zone
7
Operating Guide
A. Pairing
1. Insert the battery into the drone, and then press the Power Switch to turn on the drone. All the LED indicator
Lights on the drone begin to flash quickly.
2. Place the drone on a flat and level surface with the head forward and the tail towards the pilot. The head
side indicated with two green led lights, tail with two red led lights.
It is necessary to ensure that the drone to be placed on a flat and level surface, because the
gyroscope inside the drone needs to be corrected with water level after power-on, then it could be
in controlled normally.
3. Install the batteries for the transmitter and press the power button, one beep will be heard from the transmitter,
and all the LED indicators on the drone will turn to solid if the drone is paired successfully.
B. Calibrating the Gyro
Calibration of the gyroscope
Simultaneously push the joysticks to the lower right corner to calibrate the gyroscope, when all the drone's
indicator lights change from quick flash to solid lights, the gyroscope calibration is completed.
C. Calibrating the Compass
1. Simultaneously push the joysticks to the lower left corner to calibrate the compass.
2. All the drone's indicator lights and the compass indicator light
3. Hold the drone in the air and cross rotate it like a shape of "∞"for about 3 times until you can hear a sound
like "beep" from the transmitter.
4. All the drone's indicator lights turn to solid, the compass indicator light
completed.
Important
on the transmitter start flashing quickly.
turns off, the compass calibration is
