Specifications - tech rc Explorer TR016W Manual

Specifications:

● Drone
MODEL：TR016W
Weight (Including Battery) ：248g
Flight Time：15-18 minutes
WIFI Distance： 300-400m（Outdoor And Unobstructed）
Motor Model：Coreless motor 1020
Hovering：Enabled
Operating Temperature Range ：32° to 104° F ( 0° to 40° C )
Satellite Systems GPS / GLONASS
● Camera
Lens：FOV 120°
Still Photography Modes：Single shot
Video Recording Modes：1920*1080 (SD card) / 1280*720 (smart phone)
Photo：JPEG
Video：AVI
Supported SD Cards：TF Card 64GB (not included)
Operating Temperature：32° to 104° F ( 0° to 40° C )
● Flight Battery
Capacity：1200 mAh
Voltage：7.4V
Battery Type：Lithium battery
Energy：8.88Wh
Net Weight：38 g /1.34oz
Max Charging Time：about 150 min(Depending on Charging Power)
Charging Temperature Range：14° to 104° F ( -10° to 40° C )
● USB Cable
Voltage：5V
Common Problems and Solutions
THE PROBLEMS
Drone flashes and don't
1. Transmitter is not synced
respond to the transmitter
to the drone.
2. Insufficient battery power.
during operation.
1. Insufficient battery power.
The propellers spin, but
2. The propellers are installed
in wrong orientation.
the drone cannot take-off.
3.The propellers are distorted.
1.The propellers are distorted.
The drone shakes heavily.
2.Axle is bent.
Drone cannot stay balanced 1. The propellers are distorted.
in flight even if adjust the tuning 2. The motor doesn't work
button. properly.
The gyroscope loses it's
Drone is unstable after
crashing.
balance after crashing.
REASONS SOLUTIONS
1. Refer to the Manual and
re-sync the drone.
2. Recharge the battery.
1. Recharge the battery.
2. Install the propellers in right
orientation.
3. Replace the propellers.
1. Replace the propellers.
2. Replace the axle.
1. Replace the propellers.
2. Replace the motor.
Restart and re-calibrate the
drone.
17
Accessories(additional purchase)
Available accessories are shown as follows. For convenient purchasing of customers, every part is listed
particularly. Customers can purchase accessories through local dealers.
TR016W-1 TR016W -2
Upper shell cover Lower shell cover
TR016W-5 TR016W-6
Transmission gear Lampshade
TR016W-9 TR016W-10
Hollow steel tube Clockwise motor
(Red and blue line)
TR016W-13 TR016W-14
5G camera plate White light with plug cord
TR016W-17 TR016W-18
GPS module Mobile phone clamp
TR016W -3 TR016W-4
Propeller Foot pad
TR016W-7
TR016W-8
Motor cabinet
Drone battery
TR016W-12
TR016W-11
Receiving panel
Counterclockwise motor
(Black and white line)
TR016W-15 TR016W-16
USB charging cable Transmitter
18
