- Page 1 User manual Zitzi Active...
-
Page 2: Table Of Contents
Rest handle ............. 13 Terms of sale ..........26 Knee support ..........14 Technical data ..........27 This product is manufactured by Anatomic SITT AB Postal address Anatomic SITT AB, Box 6137, SE-600 06 Norrköping Street address Anatomic SITT AB, Terminalgatan 1, SE-603 61 Norrköping... -
Page 3: Safety Precautions
Safety precautions Introduction In order to use the Zitzi Active in its full extent, it is important that you read this manual. This applies to everyone close to the user. The product is intended for users with seating problems and fits many different kinds of diagnoses. -
Page 4: Tool
Insert the back profile down into the socket pins and tighten the four screws provided (red in the picture). The back will automatically be in the right place, using the stop in the back profile. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 5: Back Angle Adjustment
When you reach the desired angle, release the lever again. It is very important that the lever is in the safety mode, resting downwards, when the adjustments are done. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 6: Back Height Adjustment
Back depth adjustment • Release the knob B (see pic)on both sides of the back profile. • Adjust the back depth C to the desired depth. • Lock the knob. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 7: Adjustment Of Seat Position
If you want a trimmed edge padding, it can easily be cut to the desired length. Adaption with seatslope pillow The seatslope pillow can also be removed, sanded or replaced with other material. Edge padding Seatslope pillow User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 8: Headrest
If the headrest need to be higher, loosen the knob (B) and then adjust the headrest into to desired position. Tighten the knob (B). Height adjustment knob Headrest bracket, 4 bolts with pins = Adjustment bolts User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 9: Hipbelt
Mounting of antirotation belt Thread both straps through the slot in the seat (C) and down through the buckle (B) and (D). Clamp the belt straps firmly into the buckles. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 10: Chest Harness
Be sure that there is enough space for the neck, that the cushions are in the right = Adjustment bolts place and that the pressure is correct! User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 11: Chestbelt
Mounting chest belt Mounting of the straps to the chest harness is done by pulling the strap through the trunk support as shown in the figure to the right. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 12: Armrest From Back
Adjusting the lateral angle To adjust the lateral angle of the armrest, loosen the screws (F) and move the armrest to the desired angle, then tighten the screws (F). User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 13: Rest Handle
Loosen knob (D) and then adjust to the desired angle. Lock the knob when the desired angle is reached. Important - After adjusting, the tags must be interlocked to lock. Tighten the knob hard! User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 14: Knee Support
2. High placement - knee support Adjustment of the knee support The knee support can be clamped with the practical buckle which has a built-in clamping arm and release button. Clamping- Release button User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 15: Support Table
1) Take away the allen key from the top of the back profile. 2) Mount the pins (A) in the tracks of the back profile. 3) Tighten screws when desired position is reached. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 16: Footrest Whole
Loosen screw (E) (both stays), nd adjust to desired position. Tighten screws when desired position is reached. Important! - After adjusting, the tags must be interlocked to lock. = Adjustment bolts User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 17: Footrest, Divided Joint
Tighten when desired positions is reached. Angle adjusting, foot plate Loosen screws (E) for foot plate and adjust to desired angle. Tighten screws propertly. = Adjustment bolts User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 18: Calf Support
Lock the screws (A). Side-/angle adjustment - calf support Loosen the screws (B) a little, then adjust the calf plate sideways and angle. Tighten the screws (B). = Adjustment bolts User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 19: Foot Strap
The footplate is prepared for mounting of the ankle holder. Mountening of ankle holders on a whole adjustable and divided adjustable footrest are made underneath the footrest. Be sure that the pad not folded on the ankle holder. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 20: Underframe Flipper Pro G2
4 st 4 st 4 st NOTE! Never use any screws other than the supplied screws. These are security details. If other dimensions are desirable, contact Anatomic SITT AB. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... - Page 21 When using the adapter system universal, the safety strap on the seat system’s back should be used and fastened around the driving bow or equivalent on the underframe. Please refer to the separate user manuals for handling the underframe. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00...
-
Page 22: Underframe Seastar
(C) is tightened. For angle adjustment of the footrest, the knob (D) is screwed in or out to allow the footplate to reach the desired angle. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 23: Maintenance Instructions
Anatomic SITT. For other combinations please contact Anatomic SITT AB. Spare parts For the CE marking of the Zitzi Active to be valid, the seating system may only be fitted with spare parts delivered by Anatomic SITT AB. User manual Zitzi Active... -
Page 24: Summary And Follow-Ups
Marking Zitzi Active and its accessories are CE marked products. A unique serial number is located on a label placed under the activation housing. This serial number should be quoted in any correspondence regarding the product. -
Page 25: Adaptation And Customization
Adaptation and customization Guidelines and recommendations Every time the Zitzi Active is altered in some way, an assessment has to be made to determine if it is an adaptation or a customization. An adaptation is any change made in comprehension of the CE mark. All other changes are customizations. -
Page 26: Terms Of Sale
40% of the invoice value For products returned more than 360 days from delivery no refund is made for the products Customized products cannot be returned. User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... -
Page 27: Technical Data
User manual Zitzi Active www.anatomicsitt.com | +46 11 16 18 00... - Page 28 Anatomic SITT AB (Manufacturer) Box 6137, SE-600 06 Norrköping, Sweden Tel +46 11 16 18 00 Fax +46 11 16 20 05 Visiting address Terminalgatan 1, SE-602 29 Norrköping, Sweden Anatomic SITT A/S Viengevej 4, 8240 Risskov, Denmark Tel +45 86 17 01 74...
