Summary of Contents for Anatomic SITT Zitzi Flipper Pro
- Page 1 Gas piston Electric User Manual Zitzi Flipper Pro...
-
Page 2: Table Of Contents
Maintenance instructions ........17 Reconditioning ............. 17 Spare patrs ............17 Markning ..............18 Warranty ..............18 Comb. & suitable seating system ..... 18 Disassembly & Dismantlement ......19 Technical data ............19 User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 3: Safety Precautions
Safety precautions Introduction In order to use the Zitzi Flipper Pro in its full extent, it is important that you read this manual. This applies to everyone close to the user. The product is intended for users with seating problems and fits many different kinds of diagnoses. -
Page 4: Adjustable Seat Height - Gas Piston
• Let go of the foot pedal when you achieved the desired height. The height is now locked Note! Be careful to avoid risk of pinching Zitzi Flipper Pro fully lowered User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 5: Adjustable Seat Height - Electric
Keep in mind that you always should have a hand on the seating system when you are adjusting it. Note! Be careful to avoid risk of pinching • Up arrow raises the seat plate • Down arrow lowers the seat plate User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 6: Charging The Battery
The actuator for the tiltfunction then should be connected to the box input marked 2. HAND CONTROL ACTUATOR (TILT) opyion ACTUATOR (LIFT) User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 7: Tilt Function
Lock the knob (A) to ensure that tilt position is locked. Note! It is very important that the knob (A) is released before using the electric tilt function. User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 8: Driving Bows
The bow shall be mounted on the top of the tube. Use Locktite when re-mounting the rear wheels. The spacer shall only be used on Flipper Pro size 3. Spacer User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 9: Parking Brake And Directional Lock
• Unlocking Unlock the wheels by stepping Unlocked brake or Locked brake or on the front edge of the pedal directional lock directional lock activated deactivated User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 10: Mounting Of A Seat System
Mounting of a seat system A seating system can easily be mounted on Zitzi Flipper Pro with a mounting plate. The mounting plate is equipped with 4 bolts that makes the seating system stays in place. The knob beneath the mounting plate makes sure that the seating system do not lose its position. -
Page 11: Footrest
Tighten when desired positions is reached. Height adjustment, foot plate - C Loosen the screws (E) and adjust to desired position. Tighten when desired positions is reached. User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 12: Calf Support
Tighten the screws when the desired setting is reached. Release screws B to adjust the width of calf support. Tighten the screws when the desired setting is reached. = Adjustment bolts User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 13: Footrest High Edge, Single Stay
The plastic stay (H) may after adjustment of desired height be cut or heated in under the footrest plate according to personal preference. Drillhole markings can also be found under the foot plate. User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 14: From Single Stay To Double Stay
990041 / 990046 140 mm 130 mm 990042 / 990047 170 mm 160 mm 990043 / 990048 205 mm 190 mm 990044 / 990049 235 mm 240 mm User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 15: Drilling Instr. Whole Footrest Plate
Size 3 Size 4 Delfi Pro & Anatomic Sits single stay Anatomic Sits Anatomic Sits Seabass Pro Anatomic Sits & Clozitt single stay double stay double stay double stay User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 16: Drilling Instr. Divided Footrest Plate
Anatomic Sits & Sharky Pro double stay Size 3 Size 4 Delfi Pro & Anatomic Sits Seabass Pro, Clozitt single stay & Anatomic Sits double stay Anatomic Sits double stay User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 17: Maintenance Instructions
The electronics are IP-rated: IPX0. This means that it should only be cleaned with a damp cloth. Spare parts Zitzi Flipper Pro may only be provided with spare parts delivered by Anatomic SITT AB. User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 18: Markning
Combinations & suitable seating system The product fits the seating systems, Zitzi Delfi Pro, Zitzi Sharky Pro & Anatomic SITS. For other combinations, please contact Anatomic SITT AB. User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... -
Page 19: Disassembly & Dismantlement
58 cm Total weight 17, 18, 19 kg 19, 20, 21 kg Sizes Max user weight (Size 1, 2 and 3) 35, 50, 75 kg 35, 50, 75 kg User manual Zitzi Flipper Pro www.anatomicsitt.com | +46 11 16 18 00... - Page 20 Anatomic SITT AB (manufacturer) Box 6137, SE-600 06 Norrköping, Sweden Phone +46 11 16 18 00 Fax +46 11 16 20 05 Support +46 11 16 18 05 Street address Terminalgatan 1, SE-602 29 Norrköping, Sweden Anatomic SITT A/S Viengevej 4, 8240 Risskov, Denmark...
