- Page 1 T-10 Meter Assembly Instructions...
- Page 2 Chamber Assembly Upper Half Thrust Roller Diaphragm Ball and Disc Outlet Gasket **Please note Outlet Gasket will be removed for competition. Lower Half...
- Page 3 Chamber Assembly Thrust Roller Ball and Disc Insert thrust roller in the ball and disc.
- Page 4 Chamber Assembly Lower Half Ball and Disc Insert ball and disc into lower half.
- Page 5 Chamber Assembly Diaphragm Lower Half Insert diaphragm into lower half.
- Page 6 Chamber Assembly Upper Half Lower Half Snap upper and lower half together.
- Page 7 Chamber Assembly Chamber Outlet Gasket **Please note Outlet Gasket will be removed for competition. Insert outlet gasket into chamber.
- Page 8 Meter Assembly Maincase Chamber Assembly Place chamber assembly into meter maincase. Ensure outlet gasket is facing the outlet of the meter.
- Page 9 Meter Assembly Maincase Strainer Place strainer into meter maincase as shown above. Ensure the strainer is fully seated and flush with the machined surface.
- Page 10 Meter Assembly Meter Outlet Liner/Gasket Place liner/gasket into meter maincase. Ensure liner/gasket dome is facing up away from meter.
- Page 11 Meter Assembly Meter Bottom Cap Place bottom cap on meter maincase.
- Page 12 Meter Assembly Meter Bolts Insert bolts into maincase and tighten them with your finger.
- Page 13 Meter Assembly ½” Wrench Finish tightening bolts with ½” wrench.
- Page 14 Complete Meter Assembly Register Flip meter over and place register on bayonet. Secure by turning the register clockwise.
