- Page 1 Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
- Page 3 Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
- Page 4 Copyright This manual is an unpublished work and contains the trade secrets and confidential information of Neptune Technology Group Inc., which are not to be divulged to third parties and may not be reproduced or transmitted in whole or part, in any form or by any means, electronic or mechanical for any purpose, without the express written permission of Neptune Technology Group Inc.
- Page 5 RF Exposure Information This equipment complies with the FCC RF radiation requirements for uncontrolled environments. To maintain compliance with these requirements, the antenna and any radiating elements should be installed to ensure that a minimum separation distance of 20 cm is maintained from the general population.
- Page 6 Cellular MIU (CMIU™) Pit and Wall Neptune Technology Group Inc. Installation and Maintenance Guide 1600 Alabama Highway 229 Literature No. IM CMIU 04.19 Tallassee, AL 36078 Part No. 13682-001 Tel: (800) 633-8754 Fax: (334) 283-7293 Copyright © 2003 - 2019 Firmware © 2016 - 2019 Neptune Technology Group Inc.
-
Page 7: Table Of Contents
Prior to Installation Storage Unpacking Tools and Materials Site Selection Installing the CMIU™ Removing the Main Housing Applying the Scotchlok™ Gel Caps Completing and Testing the Installation Testing the Installation Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... - Page 8 Six Wheel Encoders Four Wheel Encoders Troubleshooting Contact Information By Phone By Email Appendix A: CMIU™ Modes Appendix B: CMIU™ Manager CMIU™ Status Meter Reading Cellular Network Glossary Index viii Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
- Page 9 Figure 1 – Cellular MIU – Wall Figure 2 – Cellular MIU – Pit Figure 3 – CMIU™ Pit Dimensions - Front and Side Figure 4 – CMIU™ Wall Dimensions - Front and Side Figure 5 – Wiring a Neptune Encoder Register Figure 6 –...
- Page 10 Figure 40 – Three Colored Wires Properly Connected Figure 41 – Splice Tube Figure 42 – Gray Wires in Slots Figure 43 – Attaching the CMIU™ to the Antenna Shaft Figure 44 – Swiping the CMIU™ Figure 45 – CMIU™ Status Screen Figure 46 –...
- Page 11 Table 5 – Recommended Tools Table 6 – Recommended Materials Table 7 – Maximum Cable Lengths Table 8 – Cable Length and Manufacturer Table 9 – Example Reading Values Table 10 – CMIU™ Modes Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
- Page 12 Tables This page intentionally left blank Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
-
Page 13: Chapter 1: Product Description
The CMIU is easily installed in wall or pit applications. It operates on AT&T or Verizon 4G LTE cellular networks. The CMIU stops RF transmissions when the battery discharges below the normal operating voltage. - Page 14 Chapter 1: Product Description This page intentionally left blank. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
-
Page 15: Chapter 2: Specifications
The length is based on solid three conductor wire, 22 AWG. ® Neptune ProRead™ and 500 feet (152 meters) ® E-CODER Sensus Protocol registers 200 feet (61 meters) Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 16: Environmental
Chapter 2: Specifications Environmental The following table provides the environmental specifications of the CMIU. Table 3 – Environmental Conditions Condition Description Operating Temperature –22° to 149°F (–30° to 65°C) Storage Temperature –40° to 158°F (–40° to 70°C) Operating Humidity 0 to 100% condensing Functional The following table provides the functional specifications of the CMIU. -
Page 17: Figure 4 - Cmiu™ Wall Dimensions - Front And Side
Chapter 2: Specifications Figure 4 – CMIU™ Wall Dimensions - Front and Side Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... - Page 18 Chapter 2: Specifications This page intentionally left blank. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
-
Page 19: Chapter 3: General Installation Guidelines
Chapter 3: General Installation Guidelines This chapter describes tools, materials, and general installation guidelines for the CMIU™. Tools and Materials Chapter 3 defines the recommended tools and materials you need to successfully install the CMIU. Some items may not apply to your specific installation, or the list may not contain all required tools or materials. -
Page 20: Recommended Materials
Notify the customer of your presence, and tell the customer that you need access to the water meter. Write the ID numbers of the CMIU you are installing, if the site work order does not include the numbers. Verify that the ID numbers match the ID numbers on the CMIU you are installing, if the site work order already includes them. -
Page 21: Installing A Register (Non Pre-Wired Or Potted Only)
When using a ProRead encoder register, the non-AutoDetect ProRead register must be programmed for three-wire mode. If connecting the CMIU to a new ProRead encoder register, or if a three-conductor cable is already connected to a ProRead encoder register, ensure that the ProRead register is programmed for three-wire mode using the field programmer, and the format is set to (NTG) RF MIU Transport Driver Interface format (TDI). -
Page 22: Figure 5 - Wiring A Neptune Encoder Register
Figure 5 – Wiring a Neptune Encoder Register 7. If required, connect the three conductor wires to the encoder register's terminal per the manufacturer's instructions. Figure 6 – CMIU™ Color Code for Wires Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 23: Figure 7 - Cable Threaded Around Strain Relief Posts
9. Apply sealant liberally and ensure that it encapsulates the terminal screws and exposed wires. Neptune requires Novagard G661 sealant or Dow ® compound 4. Figure 8 – Application of the Sealant Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 24: Figure 9 - Covering The Terminal Screws
10. Snap the cover onto the encoder register. Figure 9 – Covering the Terminal Screws 11. Run the cable to the CMIU and fasten it securely. Do not exceed maximum cable lengths as defined in "Encoder Register Interface" on page 3. If the encoder register is prewired and potted, use Schotchloks for connecting the register to the CMIU. -
Page 25: Chapter 4: Wall Installation
Handle the CMIU carefully; however, no additional special handling is required. After unpacking the CMIU, inspect it for damage. If the CMIU appears to be damaged or proves to be defective upon installation, notify your Neptune sales representative. If one or more items requires reshipment, use the original cardboard box and packing material. -
Page 26: Tools And Materials
Install the CMIU approximately 5 feet above the ground. Install the CMIU in a vertical and upright position. Mount the CMIU on a flat surface like a wall, but it can also be mounted on a pipe. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 27: Installing The Cmiu
1. Remove the main housing from the adapter. Figure 12 – CMIU™ Main Housing The Hi-Lo fastener for securing the main CMIU housing to the adapter plate is shipped separately. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 28: Applying The Scotchlok™ Gel Caps
When the CMIU replaces a receptacle, use the appropriate hole to allow reuse of the receptacle's original mounting holes. When mounting the CMIU to a pipe, use the pipe clamp holes to secure the mounting adapter to a pipe. Applying the Scotchlok™ Gel Caps Follow this procedure to apply the Scotchlok™... -
Page 29: Figure 14 - Cmiu™ Color Code For Wires
5. Repeat this process until all connections are complete. 6. Store excess wire and Scotchloks in the hollow cavity in the back of the CMIU using the strain relief guides. Figure 15 – Cable in Back of Mounting Adapter... -
Page 30: Completing And Testing The Installation
Completing and Testing the Installation Follow this procedure to complete and test the installation. 1. Slide the tongue on the top of the CMIU into the groove on the top of the mounting adapter. 2. Secure the CMIU to the mounting adapter using the set screw. -
Page 31: Testing The Installation
Chapter 4: Wall Installation 3. Position the magnet against the left side of the CMIU directly in line with the Neptune logo. 4. Move the magnet up and over the top left corner of the CMIU. Figure 18 – Swiping the CMIU™... -
Page 32: Figure 20 - Selecting A Cmiu
Chapter 4: Wall Installation 2. Select a CMIU ID from the list. Figure 20 – Selecting a CMIU™ 3. Click CONNECT. Figure 21 – Connecting the CMIU™ Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 33: Verifying The Meter Reading
Chapter 4: Wall Installation 4. Verify the signal strength. If the signal strength is: Acceptable, continue to the next procedure. Not acceptable, move the CMIU to another location to improve the signal strength and test the installation again. Figure 22 – Signal Strength Verifying the Meter Reading To verify the meter reading, complete the following steps. -
Page 34: Figure 24 - Installing The Seal Wire
Figure 24 – Installing the Seal Wire 4. Verify that the requirements of the site work order have been met and that you have recorded all information. 5. Clean up the installation site before leaving. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 35: Chapter 5: Pit Installation
After completing the inspection, store the cartons in a clean, dry environment. Keep in mind that the CMIU has an internal battery. Storage for more than one year may affect product life. Be sure to use a first-in, first-out inventory control system. For more information, see "Environmental"... -
Page 36: Tools And Materials
Avoid installing the CMIU behind metal fences or walls. Make sure the pit location gives adequate room for installing both the CMIU and the pit antenna. Install the pit antenna above the lid in low traffic areas, as illustrated below, for maximum performance. -
Page 37: Pit Cmiu™ Installation
Recessing the installation reduces the range of the antenna. Figure 27 – Antenna Placement for High Traffic Areas Although the CMIU has a cable already attached (2 feet or 6 feet), some installations can require additional cable. In these cases, the maximum cable length between the encoder register and the CMIU depends on the register's manufacturer and model. -
Page 38: Installing The Antenna
2. Thread the locking nut onto the antenna, with the unthreaded end toward the lid. Figure 29 – Locking the Nut on the Antenna Figure 30 – Antenna Installation Complete Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 39: Begin The Installation
2. Apply a coating of Novagard around the base of the antenna connector and inside on the flat rubber washer. 3. Using a torque wrench, connect the coaxial cable connector to the antenna on the CMIU housing tightening it to 16 inch-pounds. -
Page 40: Figure 33 - Tightening Connector And Latch Plate
5. Seat on top of cone-shaped rubber gasket and thread onto the three-lobed plastic latch plate 6. Finger tighten the connector to depress the cone-shaped rubber gasket. This seals the coaxial cable from moisture intrusion. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 41: Installing The Scotchlok™ Connectors
Installing the Scotchlok™ Connectors Complete the following steps to install the Scotchlok™ connectors. Make sure you complete the steps outlined in "Pit CMIU™ Installation" on page 25 to install the CMIU through the lid before you install the Schotchloks. 1. Use the 3M Scotchlok-type connector to connect the CMIU wires to the encoder wires. -
Page 42: Figure 37 - Seating Connector Wires
Chapter 5: Pit Installation 3. Take a non-stripped black wire from the pigtail and a non-stripped black wire from the CMIU and insert the wires into the Scotchlok connector until fully seated. Figure 37 – Seating Connector Wires 4. Do not strip colored insulation from the wires, or strip and twist bare wires prior to inserting into a connector. -
Page 43: Figure 39 - Improper Connections
8. Repeat steps two through six for each color wire. 9. After connecting all three color wires, read the encoder register to ensure proper connections, and the CMIU is functioning properly. Figure 40 – Three Colored Wires Properly Connected Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 44: Connecting The Splice Tube
2. Separate each gray wire and place them in the slots on each side. Figure 42 – Gray Wires in Slots 3. Snap the cover closed to finish the installation. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 45: Tying The Cable And Activating The Cmiu
Do not lodge the CMIU between the meter box and any components inside the box. Figure 43 – Attaching the CMIU™ to the Antenna Shaft 2. Place the CMIU in such a way that it does not lodge itself when the pit lid is removed. 3. Swipe the CMIU with a magnet: Position the magnet against the left side of the CMIU directly in line with the Neptune logo. - Page 46 Chapter 5: Pit Installation This page intentionally left blank. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
-
Page 47: Chapter 6: Maintenance And Troubleshooting
The sixth digit displayed is a five, if the last digit on the odometer is five through nine. The sixth digit is a zero, if the last digit on the odometer is zero through four. The CMIU adds two zeros on the end to provide an eight-digit reading to the host software. -
Page 48: Contact Information
A description of what occurred and what you were doing at the time. A description of any actions taken to correct the issue. By Email To contact Neptune Support by email, send your message to support@neptunetg.com. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... -
Page 49: Appendix A: Cmiu™ Modes
Advanced Each mode has a distinct method of operation based on the frequency: Of cellular connection to transmit the meter readings. In which the CMIU interrogates the register to store meter readings. Table 10 – CMIU™ Modes Mode Register Interrogation... - Page 50 Appendix A: CMIU™ Modes This page intentionally left blank. Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
-
Page 51: Appendix B: Cmiu™ Manager
Register ID of the connected register Cellular network status The CMIU Manager is compatible with iOS version 9.3 using either an iPhone or iPad. CMIU™ Status The CMIU Status screen provides a snapshot of the current configuration of the CMIU. This... -
Page 52: Meter Reading
Appendix B: CMIU™ Manager Meter Reading An operator can use the CMIU Manager to verify a valid installation of the CMIU with a connected register. Using the Meter button, the operator can verify the meter reading and register ID. Figure 46 – Meter Reading... -
Page 53: Glossary
MIU antenna used for pit installations American Wire Gauge CMIU Cellular Meter Interface Unit Federal Comunications Commission Liquid Crystal Display (LCD) Component where the meter-reading and value-added icons are displayed Meter Interface Unit Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... - Page 54 Unique identification number given to each MIU at the factory. The default value is the last programmed, plus one. Custom serial numbers are not available. Transport Driver Interface format transmission time The time between MIU transmissions Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
-
Page 55: Index
18 manager 7, 19 testing 19 conductor wire 10 Novagard sealant 11, 27 connector, F 27 customer support 36 operating humidity 4 dimensions 4 Dow Corning 11 prewired 12 Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide... - Page 56 22 hole 22 sealant 11 signal strength 21 storage 13 strain relief posts 11 TDI 9 temperature operating 4 storage 4, 13 testing the installation 23 tool kit 7 Cellular MIU (CMIU™) Pit and Wall Installation and Maintenance Guide...
- Page 57 CMIU™ Pit and Wall 04.19 Part No. 13682-001 © Copyright 2003-2019, Neptune Technology Group Inc. Neptune is a registered trademark of Neptune Technology Group Inc.
