Content displayed
【Ready To Work 】
【Warming Up...... 】
【DMX512 Add.xxx 】
【Volume Out xxx %】
【Tip Over】
【Manual Test】

4.3 DMX Channel Description:

When using the DMX mode, two channels are occupied:
First channel
0
1-255
Second Channel
0-20
50-100
150-200

4.4 Connection to the mains

Connect the device to the mains with the power plug .The jack POWER OUT allows for power supply
of further devices .To interconnect several devices ,connect the jack POWER OUT to the input POWER
IN of the next unit all units are connected .Matching power cables with P-Con plugs are available as
accessories.IN this manner, up to 3 devices can be linked

4.5 Notes before use :

1. Place the sparking machine horizontally, and inspect for damaged at each use. If damaged, please
contact us for service. Unscrew the lid of powder tank to pour in the our powder, and then lightly
tighten the lid.
2. Before power on, please verify that the supply voltage is in conformity with the rated voltage of the
sparking machine. At power on, the machine will begin to heat for use .Connect the machine to your
selected controller.
3.The machine must be used only in a well ventilated place but not where is air flow if limited or the
machine's thermal protection system may cause a shutdown.
It means that the machine is ready and can be sparkled at any time.
It means that the machine is being heated.
Set DMX512 address: minimum 1, maximum 512
Set the amount of sparkle: minimum 1%, maximum 100%.
Dumping alarm, setting if to alarm when the inclination is less than
The priority relationships: DMX, Remote controller.
expression
45 degrees.
Manual switch sparkle, only for testing.
Function
Spark effect off
Spark effect on
Function
Pre-heat off，And the first channel is invalid
Pre-heat on，And the first channel is valid
Clear Material，And the first channel is invalid
