KWC 10.061.002 A180 Installation And Service Instructions Manual page 3

Befestigung
Fixation
Fissaggio
Fijación
Connection
EU/AUS
USA/CAN
Montage des Schlauchstop's
Montage du stop
Montagio del stop
Montaje del stop
Installation of limit stop
ø35mm /
1 3/8"
S36
Radius min.
= 50mm / 2"
c
c =
700mm, 27 9/16"
d =
500mm, 19 11/16"
d
Verlängerungsmutter L= 40mm
Ecrou allongé L= 40mm
Dado prolungato L= 40mm
Tuerca de prolongación L= 40mm
Z.503.315
Extension nut L= 40mm / 1 1/2"
3
ø36mm /
1 7/16"
