Air King AIG4 Specifications

• Inlet Grill
Low profile, circular plastic exhaust grill
• Housing
Models AIG4: Galvanized metal collar with mounting straps and
AIG6 metal back draft damper with rubber gasket to
reduce sound level during opening and closing.
Models AIG46HL: Metal housing with wiring junction box and
AIG46F metal back draft damper with rubber gasket to
reduce sound level during opening and closing.
• Lighting
Model AIG46HL: 50 watt, Halogen Lamp, UL approved for wet
locations included with unit.
Model AIG46F: E
NERGY
Fluorescent 4 Pin Lamp included with unit.

• Unit Mounting

Models AIG4: Metal mounting straps for quick and easy
AIG6 installation to joist.
Models AIG46HL: Metal housing with wiring junction box for
AIG46F quick and easy installation between joist.
• UPC Codes
AIG4: 0-83162-31131-3
AIG46HL: 0-83162-31122-1
Models
AIG4, AIK14X, AIK24Y
AIG6, AIK16X, AIK26Y
AIG46L, AIG46YL, AIK14XL
AIK14XF, AIK26YL, AIK26YF
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.
INLINE EXHAUST FAN INLET GRILLS / HOUSINGS
S 14 watt, Wet Location Compact
TAR
AIG6: 0-83162-31132-0
AIG46F: 0-83162-31141-2
A B C D E
4" 3 5 / 8 " 4 7 / 8 " 3 3 / 4 " 1 7 / 8
6" 5 5 / 8 " 7" 3 3 / 4 " 1 7 / 8
6" 5 5 / 8 " 7 3 / 32 " 6" 1 3 / 4
IN
RPM WATTS
W.G.
F
H
F
F G H
" 3 / 8 " - -
" 3 / 8 " - -
" 3 / 8 " 7 23 / 32 " 4"
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (877)-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
INLINE INLETS
HOUSINGS
A
B
C
G
A
B
C
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
D
E
D
E
Rev. A 12-06
