- Page 1 [SMARTBAY] “ONE BOX” LED HIGHBAY USER MANUAL Teknik Lighting Solutions Pty Ltd ABN: 44 608 397 913 Tel: 1300 313 780 www.tekniklighting.com.au VEET IPART APPROVED APPROVED...
- Page 2 Thank you for selecting the [SMARTBAY] “One Box” LED Highbay. Please ensure that the luminaire is installed in accordance with the below instructions. Teknik Lighting Solutions Pty Ltd assumes no responsibility for inappropriate use or installation of the product, including any associated damage caused.
-
Page 3: Installation Diagram
INSTALLATION DIAGRAM Note: Supplied safety lanyard should be used for all installation options. Hook Mount CHAIN （iron） load capacity > 30kg ³ 500mm ³ 150mm ³ 150mm Bracket Mount (Optional) -
Page 4: Dimensional Drawing
WATTAGE SWITCHABLE FUNCTION When sensor option is required, ensure sensor module is fitted and use sensor option switches as below. When non sensor option is required, ensure blanking module is fitted and use non sensor switches as below. Sensor Sensor Version No Sensor Version SENSOR NO SENSOR... -
Page 5: Sensor Information
SENSOR INSTRUCTIONS Note: When sensor option is not required, replace sensor module with supplied blanking module Silica gel soft SENSOR INFORMATION Microwave Motion Sensor Product Type 12VDC/55mA Operating Voltage 5.8GHz CW radar HF System ~ 50 Detection Angle <1W Power Consumption Max 16x12m Detection Range (DXH) 30s ~ 30min... -
Page 6: Section 1: Typical Applications
SECTION 1: TYPICAL APPLICATIONS HF MOTION DETECTOR Daylight Harvesting When the ambient light is below the selected daylight threshold lux level, The [SMARTBAY] will adjust its output to maintain that selected level. If no motion is detected for the selected hold time, the [SMARTBAY] will dim to the selected standby dimming level. -
Page 7: Section 2: Remote Control (Optional)
DETECTION PATTERN Ceiling mounting (m) Wall mounting (m) Ceiling mounting (m all mounting (m ) 2468 10 12 14 16 18 20 1 2 3 4 57 68 high sensitivity area low sensitivity area high sensitivity area low sensitivity area SECTION 2: REMOTE CONTROL (OPTIONAL) Permanent ON/OFF [ button Press button... -
Page 9: Section 3: Troubleshooting
Minimum distance from luminaire to any flammable object is 2m. In case of weight discrepancy when replacing old lamps, please ensure that the mounting structure is rated to withstand the weight of the new lamp and installation materials. For further information, please contact Teknik (www.tekniklighting.com.au) or your local distributors. - Page 10 This product utilises intellectual property in the form of registered designs, trademarks, and/or patents. Such intellectual property remains the property of Teknik Lighting Solutions Pty Ltd in all cases. This product has been designed to operate in ambient temperatures -40 C to + 50 5/26-34 Dunning Ave, Rosebery NSW 2018 | 1300 313 780 | info@tekniklighting.com.au...
