EMC
VNXe3100/VNXe3150
Replacing an Input/Output Module
P/N 300-012-217
REV 02
This document describes how to replace a faulted input/output (I/O) module in a
VNXe3100 or VNXe3150 disk processor enclosure (DPE). For information on upgrading the
existing I/O modules in a VNXe3100 or VNXe3150 DPE with a different type of I/O module,
refer to the document for upgrading I/O modules in a VNXe3100 or VNXe3150 system.
Before you begin the procedure, refer to your EMC® VNXe™ online help (Servicing your
system > Adding or replacing faulted hardware components > Replace a faulted hardware
component) for instructions on how to identify failures, order new parts, and handle
hardware components.
Task 1: Preparing the storage processor (SP) for service ............................................ 2
◆
Task 2: Remove the SP assembly............................................................................... 3
◆
Task 3: Remove the SP top cover ............................................................................... 4
◆
Task 4: Remove the faulted I/O module ..................................................................... 5
◆
Task 5: Install the replacement I/O module ............................................................... 6
◆
Task 6: Replace the SP top cover ............................................................................... 7
◆
Task 7: Install the SP assembly ................................................................................. 7
◆
Task 8: Reboot the storage processor ........................................................................ 8
◆
Task 9: Verify the operation of the replacement I/O module....................................... 8
◆
Task 10: Return the faulted I/O module ..................................................................... 8
◆

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VNXe3100 and is the answer not in the manual?

Questions and answers

Related Manuals for EMC VNXe3100

Summary of Contents for EMC VNXe3100

  • Page 1: Table Of Contents

    VNXe3100 or VNXe3150 disk processor enclosure (DPE). For information on upgrading the existing I/O modules in a VNXe3100 or VNXe3150 DPE with a different type of I/O module, refer to the document for upgrading I/O modules in a VNXe3100 or VNXe3150 system.

  • Page 2: Task 1: Preparing The Storage Processor (Sp) For Service

    Service mode and is receiving active power. 6. Wait until the SP fault LED is flashing alternating amber and blue before continuing to the next task. e0 e1 1 GBE 6Gb SAS 6Gb SAS SP fault EMC VNXe3100/VNXe3150 — Replacing an Input/Output Module...

  • Page 3: Task 2: Remove The Sp Assembly

    3. Pinch the orange tabs and pull the latches to the sides to eject the SP assembly from the chassis. 4. Pull the SP assembly straight out of the chassis and place it on a static-free surface. CL4682 EMC VNXe3100/VNXe3150 — Replacing an Input/Output Module...

  • Page 4: Task 3: Remove The Sp Top Cover

    Tasks to replace an I/O module Task 3: Remove the SP top cover 1. Press the blue button on the cover. 2. Push the cover straight back 1/4 inch. 3. Lift the cover up. CL4683 EMC VNXe3100/VNXe3150 — Replacing an Input/Output Module...

  • Page 5: Task 4: Remove The Faulted I/O Module

    1. Lift the blue latch carefully until it ejects the I/O module from the connector. CL4688 2. Lift the module out and away from the canister and place it on a static free surface. EMC VNXe3100/VNXe3150 — Replacing an Input/Output Module...

  • Page 6: Task 5: Install The Replacement I/O Module

    2. With the module aligned and parallel to the CPU board, press the latch down to fully seat the module in the connector. 3. Push down on the force point indicated on the I/O module to ensure that the module is completely seated on the processor board. CL4689 EMC VNXe3100/VNXe3150 — Replacing an Input/Output Module...

  • Page 7: Task 6: Replace The Sp Top Cover

    4. Reconnect the cables to the back of the SP assembly being sure to connect all cables to the same ports from which you removed them on the faulted SP assembly. The SP begins powering up immediately after connection to an active AC power source. EMC VNXe3100/VNXe3150 — Replacing an Input/Output Module...

  • Page 8: Task 8: Reboot The Storage Processor

    I/O module, and seal the box. 2. From Unisphere, click Support > Need more Help? > Customer replaceable parts > Return a customer replaceable part to enter the EMC Online Support website. The site includes detailed instructions on how to return faulted parts.
  • Page 9 Copyright © 2011-2012 EMC Corporation. All rights reserved. Published in the USA. Published June, 2012 EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice. The information in this publication is provided as is. EMC Corporation makes no representations or warranties of any kind with respect to the information in this publication, and specifically disclaims implied warranties of merchantability or fitness for a particular purpose.
