KCW-D
Video Demodulator for the KC Color Video System
DESCRIPTION:
The KCW-D Video Demodulator provides a
composite video output signal for the KC series
video entry system. It can be added to the KCS-
1ARD set (1 camera, 1 monitor) or the KC-1GRD
master monitor station (1 camera, 3 monitor
system). Use for viewing the picture from the
Aiphone video entry system on a CCTV monitor
or other video device.
SYSTEM LAYOUT EXAMPLE:
Motion Detector
KC-DAR
Power supplies not shown.
SPECIFICATIONS:
Power Source:
Video Output:
Video Input:
Video Output:
Video Monitoring:
Camera Activation:
Wiring Distance:
Mounting:
Dimensions (H x W x D):
Aiphone Communication Systems • 1700 130th Ave. NE • Bellevue, WA 98005
(425) 455-0510 • FAX: (425) 455-0071 • (800) 692-0200 • www.aiphone.com
KCW-D FEATURES:
compatible with CCTV monitor or RF modulator
KC-1GRD
KCW-D
Video
Demodulator
Multiplexer
24V DC, supplied by PS-24E.
Composite video, 1V peak-to-peak
Screw terminals (2). Use Aiphone #841802 from KC monitor.
Screw terminals (2). Use RG-59/U coax (copper core, 95% copper braid)
30 seconds, controlled by KC-1MRD or KC-1GRD
Press MONITOR button to activate camera
KC-1MRD or KC-1GRD to KCW-D: Max. 33'
Surface mount to with supplied brackets
5-1/2" x 3" x 1-1/2"
Composite (1V peak-to-peak) video signal
to tie into cable distribution system.
Use to record video from entry system for
security purposes
Works with KC-1MRD and KC-1GRD monitors
Video signal present when Aiphone monitor is on
Compact design, easy to install
KC-32EU
Video output
(saved still pictures)
Time Lapse VCR
KC-1HRD
Monitor
1001
