G-Force
INSTRUCTION FOR OPERATION AND MAINTENANCE
WARNING
ME0-V with Bail
Valve Handle
ME0-VPGI with Bail
Trigger Valve System
TASK FORCE TIPS LLC
MADE IN USA · tft.com
©Copyright Task Force Tips LLC 2002-2020
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/serial-
number.
This equipment is intended for use by trained and qualified emergency services personnel for
firefighting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize firefighters and maintenance personnel with the
operation, servicing, and safety procedures associated with this product. This manual should be
kept available to all operating and maintenance personnel.
Valve Handle
ME0-TPGI with
IMPULSE
MANUAL: METRO 0, 1, and 2
Fixed Gallonage Nozzles
ME1-TO
Tip Only
ME1-STO
Twist Valve
ME1-V with Bail
Valve Handle
ME1-VPGI with Bail
Valve Handle
ME1-TPGI with
IMPULSE
Trigger Valve System
1
ME2-TO
Tip Only
ME2-V with Bail
Valve Handle
ME2-VPGI with Bail
Valve Handle
ME2-BLITZ with Bail
Valve Handle
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax 219-464-7155
LIN-040 November 30, 2020 Rev15
Advertisement
Table of Contents
Related Manuals for Task Force Tips METRO 0 Series
Summary of Contents for Task Force Tips METRO 0 Series
- Page 1 Valve Handle Trigger Valve System Trigger Valve System TASK FORCE TIPS LLC 3701 Innovation Way, Valparaiso, IN 46383-9327 USA 800-348-2686 · 219-462-6161 · Fax 219-464-7155 MADE IN USA · tft.com ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15...
-
Page 2: Table Of Contents
SUPPORTING MATERIALS The following documents contain supporting safety and operating information pertaining to the equipment described in this manual. LIA-025 Foam Aspirator Manual LTT-108 Instructions for Pistol Grip Replacement ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... -
Page 3: Meaning Of Safety Signal Words
Do not direct water stream to cause injury or damage to persons or property. To prevent mechanical damage, do not drop or throw equipment. ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... -
Page 4: General Information
GENERAL INFORMATION Task Force Tips nozzles are designed to provide excellent performance under most fire fighting conditions. Their rugged construction is compatible with the use of fresh water as well as fire fighting foam solutions. SERIES RECOMMENDED NOZZLE TYPE MIN. HOSE DIA. -
Page 5: Specifications
Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of the equipment may be shortened due to the effects of corrosion, and is not covered under warranty. ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... -
Page 6: Flow Characteristics
60 GPM @ 100 PSI (K=6.0) 100 GPM @ 100 PSI (K=10.0) 20 GPM @ 75 PSI (K=2.3) 40 GPM @ 75 PSI (K=4.6) 60 GPM @ 75 PSI (K=6.9) FLOW (GPM) Figure 4.1B ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... -
Page 7: Metro 1
150 GPM @ 50 PSI (K=21.2) 200 GPM @ 75 PSI (K=23.1) 185 GPM @ 50 PSI (K=26.2) 50.0 200 GPM @ 100 PSI (K=20.0) Flow (gpm) Figure 4.2B ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... - Page 8 185 GPM @ 50 PSI (K=26.1) 250 GPM @ 75 PSI (K=28.9) 325 GPM @ 100 PSI (K=32.5) 100.0 250 GPM @ 50 PSI (K=35.4) 50.0 Flow (gpm) Figure 4.3B ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15...
-
Page 9: Flow Setting
Detents are provided at intermediate positions. The position of the valve is shown by the exposed valve flow pattern label. VALVE PO ITION FLOW PATTE N LABEL LABEL Figure 5.1.4 ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... -
Page 10: Impulse Trigger Flow Control
Loss of control or a burst hose could result in injury or death. Use caution when adjusting the closing speed, always verify performance after adjustment, and ensure that all adjustments are made by qualified personnel under the direction of the AHJ. ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... -
Page 11: Normal Operating Position
Large amounts or pieces of debris may be unflushable and can reduce the flow of the nozzle WARNING resulting in an ineffective flow. In the event of a blockage, it may be necessary to retreat to a safe area, uncouple the nozzle and remove debris. ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... -
Page 12: Use With Foam
5. Reinstall or reposition the Adjusting Screw if it has been moved from its original (3/16 in Allen Wrench) location. 6. Flow nozzle to check performance of slow closer. Adjust as needed. ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15... -
Page 13: Warranty
WARRANTY Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and workmanship during the five (5) year period from the date of purchase. -
Page 14: Maintenance
FIELD LUBRICATION All Task Force Tips nozzles are factory lubricated with high quality silicone grease. This lubricant has excellent wash out resistance, providing long term performance in firefighting nozzles. If your agency has unusually hard or sandy water, the moving parts of the nozzle may be affected. -
Page 15: Impulse Trigger Valve Lubrication
Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability for damage to equipment or injury to personnel that is a result of user service. Contact the factory or visit the web site at tft.com for parts lists, exploded views, test procedures and troubleshooting guides. -
Page 16: Operation And Inspection Checklist
Operating equipment that has failed the checklist is a misuse of this equipment. TASK FORCE TIPS LLC 3701 Innovation Way, Valparaiso, IN 46383-9327 USA 800-348-2686 · 219-462-6161 · Fax 219-464-7155 MADE IN USA · tft.com ©Copyright Task Force Tips LLC 2002-2020 LIN-040 November 30, 2020 Rev15...
