Features

1. For both internal (3.5" Drive Bay) and external use.
2. Reads and Writes
-Type I and II Compact Flash cards
TM
-IBM Microdrive
TM
-SmartMedia cards
TM
-Multimedia cards
TM
-Secured Digital cards
3. Fast file transferring between portable Memory Card, PC,
Notebooks and Mobile devices, such as
- Digital Cameras,
- Pocket PC,
- Personal Digital Assistant (PDA),
- Personal Organizers,
- Voice Recorders, etc.

Specifications

Dimension :
102(W) x 25.4(H) x125(D) mm / 4.02(W) x 1(H) x 4.92(D) in
Power Required :
+ _
USB, Action power: 5V 5%
Reads and Writes : (Hot-swapping)
Compact Flash , IBM Microdrive , SmartMedia , TM
Mutimedia , and Secure Digital TM
TM
TM
TM
TM
cards
Download / Upload files via high speed USB 1.1 Transfer
rate up to : 12Mb/Sec
Support :
Win 98 / SE/ ME/ 2000/ XP, Mac OS 8.6 or later, Linux.
Plug & Play for :
Windows ME/ XP ( no software driver required )

Hardware Setup

Using PRO II externally
Hardware setup is easy. Simply plug in the External USB
cable and USB to DC cable, your new PRO II reader/writer
is ready to operate. Please refer to the following diagram
for detail.
External
USB cable
External USB-DC cable
