RTC Setting Screen

Select the data numeric function icon
six such numeric functions for seconds, minutes, hours, date, month and year.
Enter the following data into 6 numeric data functions, all of which should be
"editable".
Register Legend
Sec
%R01
%R02 Min
%R03 Hr
%R04 Day
%R05 Mth
%R06 Yr
Finally insert a screen jump function to go back to the initial screen.
www.imopc.com
and insert it to the screen. We need to set up
Digits to display
2
2
2
2
2
4
11
Min – Max entry
0-59
0-59
0-23
1-31
1-12
1996-2095
The second
screen should
now look like the
screen opposite.
