English
GK+ Blood Glucose and β-Ketone Dual Monitoring System
®
Dear Keto-Mojo
System User,
®
Thank you for choosing the Keto-Mojo
GK+ Blood Glucose and β-Ketone Dual
®
Monitoring System! The Keto-Mojo
GK+ Blood Glucose and β-Ketone Dual
Monitoring System is designed for easy and accurate testing of blood glucose and
β-ketone levels.
Read this User's Manual carefully before you use your system. This manual will
help you use the system properly for reliable test results. Please keep your User's
Manual in a safe place, as you may want to refer to it in the future. You will also want
to keep the meter box (and any strip boxes you purchase) as your control solution
test ranges are printed or stickered on the box. You will also find manuals and other
resources, such as instructional videos, at keto-mojo.com.
®
Thank you again for choosing the Keto-Mojo
GK+ Blood Glucose and β-Ketone
Dual Monitoring System.
Test Principle and Intended Use
®
The Keto-Mojo
GK+ Blood Glucose and β-Ketone Dual Monitoring System is
®
comprised of the Keto-Mojo
GK+ Blood Glucose and β-Ketone Meter,
®
®
Keto-Mojo
Blood Glucose Test Strips and Keto-Mojo
Blood β-Ketone Test
Strips. The glucose measurement is achieved by using the amperometric detection
method. The test is based on measurement of electrical current caused by the
reaction of the glucose with the reagents on the electrode of the test strip. The blood
sample is pulled into the tip of the test strip through capillary action. Glucose in the
sample reacts with glucose enzyme and the mediator. Electrons are generated,
producing a current that has positive correlation to the glucose concentration in the
sample. After the reaction time, the glucose concentration in the sample is
displayed.
The test principle of the β-ketone is based on the amperometric detection of
β-hydroxybutyrate
(also
known
as
3-hydroxybutyrate)
in
whole
blood.
β-hydroxybutyrate is converted by the enzyme β-hydroxybutyrate dehydrogenase
i
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Keto-Mojo GK+
Summary of Contents for Keto-Mojo GK+
- Page 1 (and any strip boxes you purchase) as your control solution test ranges are printed or stickered on the box. You will also find manuals and other resources, such as instructional videos, at keto-mojo.com. ® Thank you again for choosing the Keto-Mojo GK+ Blood Glucose and β-Ketone...
- Page 2 The magnitude of electrical current resulting from this enzymatic reaction is proportional to the amount of β-hydroxybutyrate present in the sample. ® The Keto-Mojo GK+ Blood Glucose and β-Ketone Dual Monitoring System is intended to quantitatively measure the glucose concentration and/or β-ketone (beta-hydroxybutyrate) concentration in fresh capillary whole blood samples drawn from the fingertips.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Understanding Your Testing Tools……………………………..……..1 Your Meter System Overview…………………………………..………..1 Your Meter Display…………………………………………………..…...…. 2 Meter Use and Precautions..............4 Important Safety Information………………………………………..……… 4 Limitations……………………………………………………………..……... 5 Setting Up Your System……………………………………………...…….. 6 Set the Date and Time………………………………………………..…..6 Set the Beep Feature………….………………………………..………. 7 Set the Test Alarm……………………………………………..…………. -
Page 4: Understanding Your Testing Tools
CHAPTER 1: UNDERSTANDING YOUR TESTING TOOLS Your Meter System Overview ® The Keto-Mojo GK+ Blood Glucose and β-Ketone Meter and Test Strips... -
Page 5: Your Meter Display
All of the segments should be clear and look exactly like the picture below. If not, contact Keto-Mojo at 800-513-1965 (5 days a week, 10am-4pm PST) for further assistance. Please contact your healthcare professional if you need help outside of these hours. - Page 6 Indicates the temperature is not suitable for testing. Ketone warning. Indicates that a low test result may cause hypoglycemia. Notes: ® Your Keto-Mojo GK+ Blood Glucose and β-Ketone Meter is pre-set with a beep sound. The meter will beep when: • You turn on the meter.
-
Page 7: Meter Use And Precautions
GK+ Blood Glucose and β-Ketone Meter. ® ® • Use only Keto-Mojo Blood Glucose/ Keto-Mojo Blood β-Ketone Control ® Solution with your Keto-Mojo GK+ Blood Glucose and β-Ketone Meter and ® ® Keto-Mojo Blood Glucose/ Keto-Mojo Blood β-Ketone Test Strips. •... -
Page 8: Limitations
1. The meter and lancing device are for single patient use. Do not share them with anyone including other family members! Do not use on multiple patients! 2. All parts of the kit are considered biohazardous. They can potentially transmit infectious diseases from bloodborne pathogens, even after you have performed cleaning and disinfection. -
Page 9: Setting Up Your System
CHAPTER 2: SETTING UP YOUR SYSTEM Before you use your meter for the first time or if you change your meter batteries, you should check and update your meter settings. Set the Date and Time Manually Note: Before your first use of the meter for testing, it is important to adjust the meter settings to set the correct date and time, ensuring that results stored in the memory are captured correctly. -
Page 10: Set The Beep Feature
The month will now flash. Press the side button to adjust the month until the month setting is completed, then press the power button until the meter beeps to set. The day will now flash. Press the side button to adjust the day until the date setting is completed, then press the power button until the meter beeps to set. -
Page 11: Set The Test Alarm
Set the Test Alarm After the audio setting is completed, the meter will enter the test alarm setting mode; this function reminds users to take a measurement. Your meter is pre-set with the test alarm function to “OFF,” however, you can set up to 5 reminders per day. If you turn 5 test alarms on (A1, A2, A3, A4 and A5), your meter is pre-set with the following times for your convenience;... -
Page 12: Set The Meal Marker
The next alarm “A2” flashes on the display with an “OFF.” You can now set a second alarm by pressing the side button to turn on the second alarm. Do the same procedures to set the rest of the alarms. Note: If the meter is on at the test reminder time, the test alarm will not be activated. -
Page 13: Set The Ketone Warning
Follow the guidelines and instructions to successfully pair the meter with the Keto-Mojo App. Please note that data and reports in the App are not used for medical care reference by user or healthcare professionals. -
Page 14: Performing A Test
January 15, 2021. Make sure the test strip does not appear damaged. Prior to ® testing, wipe and dry the test site of fingertip with a Keto-Mojo alcohol prep pad or soapy water. Make sure there is no cream or lotion on the test site. - Page 15 ® ® The Keto-Mojo lancing device uses Keto-Mojo sterile lancets. 2. Hold the lancet firmly in the lancing device and twist the safety tab of the lancet until it loosens, then pull the safety tab off the lancet. Save the safety tab for disposing of the used lancet.
-
Page 16: Getting A Blood Drop And Testing
Note: Greater pressure of the lancing device against the puncture site will also increase the puncture depth. Getting a Blood Drop for Testing 1. Pull the cocking device back to set the lancing device. You may hear a click to indicate the lancing device is now loaded and ready for obtaining a drop of blood. -
Page 17: Discarding The Used Test Strip
Note: If the blood sample does not fill the check window, do not add a second drop. Discard the test strip and start over with a new test strip. 5. For blood glucose testing, the meter counts down from 5 to 1, and for blood β-ketone testing, the meter counts down from 9 to 1. - Page 18 2. All parts of the kit are considered biohazardous. They can potentially transmit infectious diseases from blood borne pathogens, even after you have performed cleaning and disinfection. Please follow proper precautions when handling your meter and lancing device. Removing the Used Lancet Unscrew the lancing device cover.
- Page 19 Expected Blood Glucose/β-Ketone Control Goal 1. Blood Glucose Reference Ranges Expected blood glucose values for people without diabetes: Time of Day Glucose Range Fasting and before meals <100 mg/dL 2 hours after meals <140 mg/dL Warning: • If your blood glucose result is below 50 mg/dL (or you see LO, less than 20 mg/dL) or is above 250 mg/dL (or you see HI, greater than 600 mg/dL) on the meter, please contact your healthcare professional as soon as possible.
-
Page 20: Questionable Or Inconsistent Results
After checking all of the conditions listed above, repeat the test with a new test strip. If you are still unsure of the problem, please contact Keto-Mojo at 800-513-1965 (5 days a week, 10am-4pm PST) for further assistance. Please contact your healthcare professional if you need help outside of these hours. - Page 21 Performing a Control Test Take out test strip from the test strip foil pouch. Note: Check the expiration date of the test strips. Do not use expired test strips. Insert a test strip into the meter in the direction of the arrows. The meter turns on after a beep.
- Page 22 Note: If the control solution sample does not fill the check window, do not add a second drop. Discard the test strip and start over with a new test strip. Hold it in the drop until the meter beeps and begins to count down on the screen, (from 5 seconds for glucose and from 9 seconds for ketones).
-
Page 23: Using The Meter Memory
DO NOT use the system to test blood. The system may not be working properly. If you cannot correct the problem, contact Keto-Mojo at 800-513-1965 (5 days a week,10am-4pm PST) for further assistance. Please contact your healthcare professional if you need help outside of these hours. - Page 24 Control results of blood glucose are not included in your 7, 14 and 30-day • average calculation. Viewing Your Test Results When your meter is off, press the power button to turn the meter on. After a beep, a symbol of a strip flashes on the display. Press the power button again. Your last test result will display on the screen.
-
Page 25: Maintenance And Troubleshooting
CHAPTER 4 ： MAINTENANCE AND TROUBLESHOOTING Proper maintenance is recommended for best results. Replace the AAA Batteries When the meter AAA batteries need to be replaced, the battery symbol ( ) will appear, or you may receive an E-11 error code. 1．... -
Page 26: Caring For Your Monitoring System
GK+ Blood Glucose and β-Ketone Meter should be cleaned and disinfected a minimum of once per week. Use only Clorox Healthcare Bleach Germicidal Wipes, which has been proven to be safe to use with the Keto-Mojo ® GK+ Blood Glucose and β-Ketone Meter. - Page 27 If you notice any of these external changes to your meter or any changes to the performance of your meter stop using the meter and please contact Keto-Mojo at 800-513-1965 (5 days a week,10am-4pm PST) for further assistance. Please contact your healthcare professional if you need help outside of these hours.
-
Page 28: Troubleshooting Guide
® Keto-Mojo Blood β-Ketone Test Strips. Discard the test strip and repeat the test with a new test strip. Make sure that you are ® Incorrect sample. using a blood sample or Keto-Mojo Blood ® Glucose, Keto-Mojo Blood β-Ketone Control Solution. -
Page 29: Symptoms Of High/Low Blood Glucose And Ketoacidosis
Symptoms of High/Low Blood Glucose and Ketoacidosis You can better understand your test results by being aware of the symptoms of high/low blood glucose and ketoacidosis. According to the American Diabetes Association, some of the most common symptoms are: High blood glucose Low blood glucose (Hyperglycemia): (Hypoglycemia):... -
Page 30: Technical Information
CHAPTER 5: TECHNICAL INFORMATION System Specifications Feature Specification Blood glucose: 20-600 mg/dL; Measurement Range Blood β-ketone: 0.1-8.0 mmol/L Blood Glucose/β-Ketone in fingertip capillary whole Test Measured blood Sample Fresh capillary whole blood Blood glucose: 0.8 µL; Sample Volume Blood β-ketone: 0.8 µL Blood glucose: 5 seconds;... - Page 31 ® The Keto-Mojo GK+ Blood Glucose and β-Ketone Dual Monitoring System was tested by 352 lay users using capillary blood samples and three Keto-Mojo ® Blood Glucose test strip lots. The results were compared to the YSI Model 2300 STAT PLUS Glucose Analyzer, a laboratory instrument.
-
Page 32: Warranty
Remarks: 1/1 sample with concentration ≥ 1.5 mmol/L measured and found within ± 5% of laboratory comparator. Warranty Please register your meter for warranty online at Keto-Mojo.com Note: This warranty applies only to the meter in the original purchase and does not apply...
