M-system Mini-M M2SES2 Instruction Manual page 2

High/low selector (with simple loop test output)

Advertisement

TERMINAL CONNECTIONS
Connect the unit as in the diagram below or refer to the connection diagram on the side of the unit.
■ EXTERNAL DIMENSIONS unit: mm (inch)
21.5 (.85)
10 (.39)
■ CONNECTION DIAGRAM
+
1
INPUT 1
4
+
5
INPUT 2
8
EXTERNAL VIEWS
■ FRONT VIEW
Status Indicator LED2
Status Indicator LED1
Zero Adj. (ZERO2)
Input 2
Span Adj. (SPAN2)
Zero Adj. (ZERO1)
Input 1
Span Adj. (SPAN1)
84 (3.31)
114 (4.49)
• When mounting, no extra space is needed between units.
9
+
OUTPUT
12
13
U(+)
POWER
14
V(–)
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
DIN RAIL
35mm wide
2–4.2x5
(.17x.20)
MTG HOLE
6 (.24) deep
8–M3
SCREW
[4 (.16)]
WIRING INSTRUCTIONS
■ SCREW TERMINAL
Torque: 0.8 N·m
■ SOLDERLESS TERMINAL
Refer to the drawing below for recommended ring tongue
terminal size. Spade tongue type is also applicable.
Applicable wire size: 0.25 to 1.65 mm
Recommended manufacturer: Japan Solderless Terminal
MFG.Co.Ltd, Nichifu Co.,ltd
3.3 (.13) max
■ SIDE VIEW
Output Function
Setting
1 2 3 4
ON
OFF
M2SES2
6 (.23)
4
1
8
5
12
9
14 13
15 (.59)
23 (.91)
(AWG 22 to 16)
2
mm (inch)
SW1
EM-5098 Rev.3 P. 2 / 3
