WARNING: To prevent electrical shock and/or injury disconnect fan from power source before you move or service the fan. Suitable for use with solid-state speed controls. WARNING: To reduce the risk of fire, electric shock, and injury to persons, ZOO Fans must be installed only with controllers supplied by ZOO Fans. Other parts cannot be substituted.
PRE-INSTALLATION The safe installation and operation of equipment supplied by ZOO Fans is the responsibility of the system designer, installer, maintainer, and operator (collectively, the “User”). The need for protective safety accessories to meet company standards, applicable codes, and the requirements of the Occupational Safety and Health Act (“OSHA”) must be determined by the User since safety requirements may vary depending on...
PARTS ENCLOSED If you ordered more than one fan, be sure to keep the components of each fan together. Each ZOO Fans In-Ceiling Fan will include the following: Motor Box (Box 1 of 2) ➢ Mixed-flow fan (#1 on diagram above—illustrative only, models vary in appearance) In-Ceiling Kit (Box 2 of 2) Clear Plastic Bag—...
ZOO Fans’ representative or ZOO Fans directly if you require assistance. Remember, the number of ZOO Fans required for the job, as well as where they are hung, will depend on a number of variables, some of which are: •...
STEP 2: Install Flexible Duct To ensure proper airflow, the ZOO Fans In-Ceiling fans come with two (2) plastic 90° bends (Flex 90 Elbow) designed to create a smooth, even bend where the flexible duct is attached to the intake diffuser and to the exhaust (jet ball) diffuser.
(not included) that has a minimum width of 1.5”. INSTALL FAN STEP 1: Install Joins, Reducers and Eye Hooks Install Reducers For IC15-MF Models Only (see Figure 15) For all other models, skip to the NEXT SECTION, “Install Eye Hooks” Figure 15...
1. Slide duct over the exhaust side of the fan—for EC15-MF ONLY, slide over 8” reducer on exhaust side). 2. Use duct tape and/or tap screws to secure duct to fan—for IC15-MF, use duct tape and/or tap screws to secure duct to reducer.
STEP 2: Connect fan to flexible duct (intake side) 1. Connect the flexible duct to the intake side of the fan (for IC15-MF, connect to 8” side of the reducer) by sliding the ducting over the intake side of the fan.
Page 18
WARNING: never apply line voltage to the control signals OPTION 1 – Wiring AVS-EC-Auto Please refer to ZOO Fans AVS-EC-Auto Installation Guide for wiring OPTION 2 – Wiring 10k Ohm Potentiometer Refer to diagram below and to Installation Guide for 10k Potentiometer for wiring Option 3 –...
Page 19
• Proper grounding of the controller is required for safety and proper operation. • Multiple fans may be wired in parallel to one controller; please contact ZOO Fans for detailed instructions. • Ground wire must be bonded at each location where metal boxes are used CAUTION: An incorrectly installed controller can result in component damage or reduction of the fan’s life.
