Features
Secondary display
Test frequency
Primary display
Measurement mode
(component type)
For more detailed information, please
refer to the LCR Meter Elite1 User
Manual on LCR Research website
(www.lcrresearch.com).
Second Edition, September 2015
© LCR Research Ltd. 2015
USB charging
interface
Circuit Mode
Battery
Status
Navigation button
(single, double, triple
click and hold)
LCR Meter Elite1
Quick Start Guide
WARNING
To avoid electrical hazards and
possible damage to your LCR meter
or to the equipment under test,
always discharge the capacitor to be
tested before measuring. For in-circuit
measurement, always disconnect
circuit power and discharge all
high-voltage capacitors before testing.
This device complies with the Class A of FCC Part
15, Subpart B and IC ICES-003.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LCR Elite1
Summary of Contents for LCR Elite1
- Page 1 For in-circuit For more detailed information, please measurement, always disconnect refer to the LCR Meter Elite1 User circuit power and discharge all Manual on LCR Research website high-voltage capacitors before testing.
- Page 2 Four Charging the Battery testing frequencies can be selected as displayed in the ow chart below. The LCR meter is powered by an internal, lithium-ion polymer rechargeable battery. It can be charged by a computer or a USB Auto frequency mode power adapter (available separately).
