Specifications; Mechanical - Task Force Tips ThunderFog Series Manual

ON
C) BALL VALVE WITH
ON
E) QUADRACUP RETRACTED POSITION

3.2 SPECIFICATIONS

3.2.1 MECHANICAL

Maximum nozzle inlet pressure
with valve shut off
Operating temperature range of fl uid
Storage temperature range of fl uid
Materials used
©Copyright Task Force Tips LLC 2002 - 2020
OFF
Index Ring
Pistol Grip
PISTOL GRIP
Figure 3.1C
OFF
Ball Valve Handle
Model Number
Serial Number
Operating Pressure
Figure 3.1E
1" Quadrafog
1" Quadrafog
1.5" Quadrafog & Quadracup 300 psi
1.5" & 2.5" Thunderfog
33 to 120° F
-40 to 150° F
Aluminum 6000 series hard anodized MIL 8625 class 3 type 2, stainless
steel 300 series, nylon 6-6, nitrile rubber
ON
F) QUADRACUP EXTENDED POSITION
300 psi Standard Model
800 psi High Pressure Model 55 bar
300 psi
Table 3.2.1
6
Playpipe Handle
D) PLAYPIPE
Figure 3.1D
OFF
Shaper
Aspirating Sleeve
Pistol Grip
Figure 3.1F
21 bar
21 bar
21 bar
1 to 50° C
-40 to 65° C
LKF-100 January 22, 2020 Rev20
