3.0 GENERAL INFORMATION

This manual describes nozzles calibrated at 100 psi (7 bar) and 75 psi (5 bar). Contact the factory for data specifi c to models
that operate with metric fl ow calibrations. ThunderFog, QuadraFog, and QuadraCup are economical, lightweight, and dependable
nozzles. Their rugged construction is compatible with the use of fresh water as well as fi refi ghting foam solutions. Other important
operating features include:
• Quick-acting pattern control from straight stream to wide fog
• Fixed fog teeth
• Metal spinning fog teeth available on some models
• Easily fl ushable while fl owing to clear trapped debris
• Quick-change rear valve seat
• TFT's 5-year warranty and unsurpassed customer service

3.1 VARIOUS MODELS AND TERMS

The nozzle is available in several diff erent models and inlet connections. Basic body styles are shown below.
Selectable Flow: A nozzle with a discharge orifi ce that can be set to a user selected position. In each position the nozzle acts as a
fi xed orifi ce nozzle.
Tip Only: A nozzle without an integral ball shuttoff valve.
ThunderFog, QuadraFog, and QuadraCup nozzles are available in a variety of fl ow ranges and confi gurations. All models deliver the
selected fl ow when the rated pressure is supplied to the nozzle. Flow settings and recommended hose sizes are:
SERIES
INCHES
1" QUADRAFOG
1" QUADRAFOG
1.5" QUADRAFOG
1.5" QUADRACUP
1.5" THUNDERFOG 1-1/2 to 1-3/4
2.5" THUNDERFOG 1-1/2 to 2-1/2
* Other threads, coupling sizes, or connector styles can be specifi ed at time of order.
ThunderFog, QuadraFog, and QuadraCup nozzles are available in several models.
Coupling
A) TIP ONLY
Figure 3.1A
©Copyright Task Force Tips LLC 2002 - 2020
RECOMMENDED
HOSE SIZE
MM
3/4, 1 19, 25
3/4, 1 19, 25
1-1/2 38
1-1/2 38
38 to 45 30, 60, 95, 125, 150, 200
38 to 64 95, 125, 150, 200, 250
Shaper
FLOW SETTINGS
@100 PSI (7bar)
GPM
5, 10, 24, 40
5, 10, 25, 40, 60 20, 40, 100, 150, 230
30, 60, 95, 125
30, 60, 95, 125
115, 230, 360, 475, 550, 750
360, 475, 550, 750, 1000
Table 3.1
ON
Model Number
Serial Number
Operating Pressure
5
l/min
20, 40, 100, 150
115, 230, 360, 475
115, 230, 360, 475 Selectable Flow, Foam
OFF
Ball Valve Handle
B) BALL VALVE
Figure 3.1B
LKF-100 January 22, 2020 Rev20
NOZZLE TYPE
Selectable Flow
Selectable Flow
Selectable Flow
Selectable Flow
Selectable Flow
