1.0 MEANING OF SAFETY SIGNAL WORDS

A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the definitions of the four signal words are as follows:
DANGER
WARNING
CAUTION
NOTICE

2.0 SAFETY

DANGER
WARNING
WARNING
CAUTION

3.0 GENERAL INFORMATION

The Extend-A-Gun is a telescoping waterway designed to maximize firefighter safety while expanding the capabilities of deck
mounted Master Stream devices. Its function is to elevate a mounted Master Stream device above other equipment on the apparatus,
providing greater clearance and freedom of movement to the device. Operators control elevation both to and from the storage
position by manually lifting and lowering the monitor. The Extend-A-Gun features a hard coat anodized aluminum finish and built in
sensor for connection to "monitor raised" light. The Extend-A-Gun features a 3" diameter waterway.

3.1 SPECIFICATIONS

Waterway Size
Maximum Flow
Maximum Pressure
Lifting Capability
Operating Temperature Range

3.2 USE WITH SALT WATER

Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of
the equipment may be shortened due to the effects of corrosion, and is not covered under warranty
©Copyright Task Force Tips LLC 2002-2020
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE is used to address practices not related to physical injury.
Working from an elevated position increases the risk of falling. Wet or slippery surfaces add to
this risk. Serious injury or death could occur. Watch footing when working on top of apparatus.
The stream exiting a nozzle is very powerful and capable of causing injury and property damage.
Make sure the nozzle is securely attached and pointing in a safe direction before water is turned
on. Do not direct water stream to cause injury or damage to persons or property.
The Extend-A-Gun may be used only in either the fully raised or fully lowered position. The unit
may become damaged if the water is turned on in any position other than fully extended or
retracted.
Damage may occur if the truck drives under a low hanging object while the Extend-A-Gun RC
is extended. Shutting off the water downstream of an Extend-A-Gun in the raised position traps
water preventing retraction. Drain water from the piping and retract the Extend-A-Gun RC before
moving the apparatus.
Pressurizing a retracted waterway with closed shutoffs or caps on the monitor discharge disables
waterway extension. Relieving pressure trapped in the waterway will restore the lift function.
EXTEND-A-GUN XG12
3.0" (76mm)
1250 gpm (4800 l/min)
200 psi (13.8 bar)
100 lbs (46 kg)
-30°F to +120°F (-34°C to +49°C)
Table 3.1
4
LIX-512 August 17, 2020 Rev09
